Subaru Legacy BM/BR facelift (2012-2014) parking brake/brake fluid level warning light Wiring diagram

14 7 6 DATA LINK CONNECTOR (LEFT END OF DASH) ABS WARNING LIGHT BLK WIRE BLK/ YEL WIRE BLK/WHT WIRE BLK/YEL WIRE BLU WIRE BRAKE FLUID LEVEL SWITCH (BRAKE MASTER CYLINDER) BRN WIRE BRN/WHT WIRE CAN TRANSCEIVER, RECEIVER I/F CLUTCH STROKE SENSOR (M/T) (LEFT SIDE OF DASH) COMBINATION METER COMPUTER DATA LINES SYSTEM DRIVE CIRCUIT EPB CONTROL MODULE (UNDER REAR SEAT) FL IN FL OUT FR IN FR OUT FUSE 33 FUSE FUSE 19 FUSE 7 GB-5 (RIGHT KICK PANEL) GB-6 (LEFT KICK GRN WIRE GRN/BLK WIRE GRN/ORG WIRE GRN/YEL WIRE GV (RIGHT SIDE OF ENGINE) HILL HOLD SWITCH HOT AT ALL TIMES HOT AT ALL TIMES MAIN FUSE BOX (M/B) SBF-6 FUSE FUSE (LEFT SIDE OF ENGINE COMPT) HOT IN ON OR START HOT IN ON OR START FUSE, RELAY FUSE 5 BOX (F/B) (LEFT KICK PANEL) KEYLESS ACCESS CONTROL MODULE LEFT FRONT ABS WHEEL SPEED SENSOR (LEFT FRONT WHEEL SPINDLE ASSEMBLY) LEFT REAR ABS WHEEL SPEED SENSOR (LEFT REAR WHEEL SPINDLE ASSEMBLY) LOWER COVER SWITCH (VDC OFF) LT BLU WIRE LT GRN WIRE MICRO COMPUTER MOTOR RELAY NCA WIRE ORG/ WIRE PANEL) PARKING BRAKE/BRAKE FLUID LEVEL WARNING LIGHT PNK WIRE PRIMARY CUT PRIMARY SUCTION PUMP MOTOR RED WIRE RED/YEL WIRE RIGHT FRONT ABS WHEEL SPEED SENSOR (RIGHT FRONT WHEEL SPINDLE ASSEMBLY) RIGHT REAR ABS WHEEL SPEED SENSOR (RIGHT REAR WHEEL SPINDLE ASSEMBLY) RL IN RL OUT RR IN RR OUT SECONDARY CUT SOLENOID VALVE SECONDARY SUCTION STEERING ANGLE SENSOR (STEERING COLUMN) VALVE RELAY VDC CONTROL MODULE (RIGHT REAR CORNER OF ENGINE COMPT) VDC OFF IND VDC WARNING LIGHT/VDC OPERATION IND LIGHT VIO WIRE VIO/GRN WIRE VIO/RED WIRE WHT WIRE WHT/BLU WIRE WHT/RED WIRE YAW RATE, G SENSOR YEL/BLK WIRE YEL/WHT WIRE
