Subaru Legacy BM/BR facelift (2012-2014) outback model Wiring diagrams
This page contains all the electrical diagrams for the component. outback model, in which he is found in the car Subaru Legacy BM/BR facelift (2012-2014). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram outback model (1 of 2)
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BLU/WHT WIRE
FUSE 17
FUSE 22
FUSE, RELAY BOX (F/B) (LEFT KICK PANEL)
GB-5 (RIGHT KICK PANEL)
GB-6 (LEFT KICK PANEL)
HOT AT ALL TIMES
LEFT OUTER MIRROR ASSEMBLY
MAIN FUSE BOX (M/B) (LEFT SIDE OF ENGINE COMPT)
MAIN SBF FUSE
MIRROR HEATER
MIRROR HEATER RELAY
NCA WIRE
OUTBACK MODEL
REAR DEFOGGER
REAR DEFOGGER RELAY
RED WIRE
RED/BLU WIRE
RIGHT OUTER MIRROR ASSEMBLY
YEL WIRE
Go to component -> Heated mirrors circuit -> OUTBACK MODEL
Wiring diagram outback model (2 of 2)
12 6 4 10 REAR DEFOGGER SWITCH
A/C CONTROL MODULE (BEHIND RIGHT J/C SIDE OF DASH)
A/C CONTROL PANEL
BLK WIRE
BLK/YEL WIRE
BLU WIRE
BODY INTEGRATED UNIT (CENTER OF DASH)
FUSE 22
GB-11 (OUTBACK) (RIGHT TOP OF REAR GATE)
GRN WIRE
GRN/ORG WIRE
HOT AT ALL TIMES
HOT IN ON OR START FUSE, RELAY BOX (F/B) (LEFT KICK PANEL)
J/C
MAIN FUSE BOX (M/B) (LEFT SIDE OF ENGINE COMPT)
MAIN SBF FUSE
MANUAL A/C AUTOMATIC A/C
MIRROR HEATER RELAY
NCA WIRE
OUTBACK MODEL
REAR DEFOGGER
REAR DEFOGGER RELAY
RED WIRE
RED/BLU WIRE
VIO WIRE
VIO/GRN WIRE
WHT WIRE
WHT/BLK WIRE
Go to component -> Rear defogger circuit -> OUTBACK MODEL
