Subaru Legacy BM/BR facelift (2012-2014) neutral position switch Wiring diagrams
This page contains all the electrical diagrams for the component. neutral position switch, in which he is found in the car Subaru Legacy BM/BR facelift (2012-2014). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram neutral position switch (1 of 2)
BATTERY
BLK WIRE
BLK/BLU WIRE
BLK/GRN WIRE
BLK/WHT WIRE
BLK/YEL WIRE
CLUTCH STROKE SENSOR (CLUTCH START SWITCH) (LEFT SIDE OF DASH)
CVT
CVT M/T
ECM (RIGHT SIDE OF DASH)
FUSE 21
FUSE, RELAY BOX (F/B) (LEFT KICK PANEL)
GRN/BLK WIRE
IGNITION SWITCH
INHIBITOR SWITCH (TOP OF TRANSMISSION)
M/T
MAIN FUSE BOX (M/B) MAIN SBF FUSE (LEFT SIDE OF ENGINE COMPT)
NCA WIRE
NEUTRAL POSITION SWITCH
OFF ON
SBF-5 FUSE
STARTER MOTOR
STARTER RELAY FUSE, RELAY BOX (F/B)
WHT WIRE
WHT/BLK (OR WHT) WIRE
WHT/BLK WIRE
WHT/BLU WIRE
WHT/GRN WIRE
Go to component -> 2.5l, starting circuit, without push button start -> NEUTRAL POSITION SWITCH
Wiring diagram neutral position switch (2 of 2)
3.6L 2.5L
A/T, M/T CVT
ACCELERATOR PEDAL POSITION SENSOR
BLK WIRE
BLK/BLU WIRE
BLK/GRN WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
BLU/RED WIRE
BLU/YEL WIRE
BRN WIRE
BRN/WHT WIRE
CLUTCH SWITCH (M/T) (LEFT SIDE OF DASH)
CRUISE
CRUISE CONTROL SWITCH
ECM (RIGHT SIDE OF DASH)
ELECTRIC THROTTLE CONTROL RELAY (IN RELAY HOLDER)
ELECTRONIC THROTTLE CONTROL (REAR OF ENGINE)
FUSE
FUSE 12
FUSE 4
FUSE 5
FUSE 7
FUSE 8
FUSE, RELAY BOX (F/B) (LEFT KICK PANEL)
GE (2.5L: RIGHT REAR OF ENGINE) (EXCEPT 2.5L: LEFT REAR OF ENGINE)
GRN/BLK WIRE
GRN/RED WIRE
GRN/YEL WIRE
HOT AT ALL TIMES
HOT IN ON OR START
HOT W/
INHIBITOR RELAY (ON SMART MODULE BRACKET)
INHIBITOR SWITCH (TOP OF TRANSMISSION)
LT GRN WIRE
MAIN FUSE BOX (M/B) (LEFT SIDE OF ENGINE COMPT)
MAIN RELAY (IN RELAY HOLDER)
NCA WIRE
NEUTRAL POSITION SWITCH
ORG/ WIRE
RED WIRE
RED/BLU WIRE
RED/YEL WIRE
RES+
SET-
SHIELD
SHIELD 3.6L SHIELD SHIELD 2.5L
STARTING/ CHARGING SYSTEM
TCM (LEFT SIDE OF DASH)
WHT WIRE
WHT/BLK WIRE
WHT/BLU WIRE
YEL WIRE
YEL/BLU WIRE
YEL/GRN WIRE
YEL/PNK WIRE
Go to component -> Cruise control circuit (1 of 2) -> NEUTRAL POSITION SWITCH
