Subaru Legacy BM/BR facelift (2012-2014) manual mode switch at select lever Wiring diagrams
This page contains all the electrical diagrams for the component. manual mode switch at select lever, in which he is found in the car Subaru Legacy BM/BR facelift (2012-2014). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram manual mode switch at select lever (1 of 2)
BLK WIRE
BLK/YEL WIRE
BLU WIRE
BLU/BLK WIRE
BLU/WHT WIRE
BRN/RED WIRE
BRN/WHT WIRE
COMPUTER DATA LINES SYSTEM
DOWN
ENGINE CONTROLS SYSTEM
FUSE 16 FUSE 17 (LEFT SIDE OF ENGINE COMPT)
FUSE 5 FUSE 12
FUSE 7
GRN/BLK WIRE
GRN/RED WIRE
HOT AT ALL TIMES
HOT AT ALL TIMES FUSE, RELAY BOX (F/B) (LEFT KICK PANEL)
HOT IN ON OR START
J/C
MAIN FUSE BOX (M/B)
MANUAL MODE SWITCH AT SELECT LEVER
NCA WIRE
ORG/BLK WIRE
PADDLE SHIFT SWITCH
REAR VEHICLE SPEED SENSOR (REAR OF TRANSMISSION)
RED WIRE
ROLL CONNECTOR (LEFT SIDE OF DASH)
STARTING/CHARGING SYSTEM
TCM (LEFT SIDE OF DASH)
TURBINE SPEED SENSOR 1 (LEFT SIDE OF TRANSMISSION)
VIO/RED WIRE
WHT WIRE
WHT/BLU WIRE
WHT/RED WIRE
YEL WIRE
YEL/BLU WIRE
Go to component -> A/t circuit (1 of 2) -> MANUAL MODE SWITCH AT SELECT LEVER
Wiring diagram manual mode switch at select lever (2 of 2)
