Subaru Legacy BM/BR facelift (2012-2014) left power seat data link connector Wiring diagram
This page shows the only wiring diagram for the component.left power seat data link connector, which is found in the car Subaru Legacy BM/BR facelift (2012-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left power seat data link connector (1 of 1)
& RECEIVER
A/C CONTROL MODULE
A/C CONTROL PANEL
AUDIO SHIELD
AUTOMATIC A/C W/ REAR VIEW CAMERA
BLK WIRE
BLK/BLU WIRE
BLK/PNK WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU/RED WIRE
BODY INTEGRATED UNIT
COMBI- NATION METER CLOCK
CONNECTOR
CRANKSHAFT POSITION KNOCK SENSOR SENSOR 1 SHIELD SHIELD
ELECTRONIC THROTTLE CONTROL SHIELD
EPB CONTROL MODULE
GB-10 (BASE OF LEFT "B" PILLAR)
GB-5 (RIGHT KICK PANEL)
GB-9 (SEDAN: CENTER OF REAR PARCEL SHELF) (WAGON: LEFT "D" PILLAR)
GE (3.6L) (LEFT REAR OF ENGINE)
GRN WIRE
GV (RIGHT SIDE OF ENGINE)
HIGH LEFT REAR COMBINATION LIGHT
IGNITION COIL
IGNITION IGNITION IGNITION COIL COIL COIL
KNOCK SENSOR 2 SHIELD
LEFT POWER SEAT DATA LINK CONNECTOR
LEFT REAR COMBINATION LIGHT
LEFT REAR DOOR SWITCH
MANUAL A/C
NCA WIRE
REAR ACCESSORY POWER SUPPLY SOCKET (CARGO ROOM)
REARVIEW CAMERA SHIELD
RED WIRE
SEDAN
STERIO CAMERA
TO GROUND GB-6 (DIAGRAM 2 OF 4)
VDC CONTROL MODULE
W/ NORMAL AUDIO
WAGON
WHT/RED WIRE
YEL WIRE
Go to component -> Ground distribution circuit (3 of 4) -> LEFT POWER SEAT DATA LINK CONNECTOR
