Subaru Legacy BM/BR facelift (2012-2014) left door step light Wiring diagrams
This page contains all the electrical diagrams for the component. left door step light, in which he is found in the car Subaru Legacy BM/BR facelift (2012-2014). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram left door step light (1 of 2)
BLK WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
BLU/GRN WIRE
BLU/ORG WIRE
BLU/RED WIRE
BLU/WHT WIRE
BLU/YEL WIRE
DOOR
GB-5 (RIGHT KICK PANEL)
GB-7
GB-7 (SEDAN: CENTER FRONT OF LUGGAGE COMPT) (WAGON: RIGHT QUARTERPANEL)
J/C
LEFT DOOR STEP LIGHT
LEFT FRONT DOOR SWITCH (LEFT "B" PILLAR)
LEFT VANITY MIRROR ILLUMINATION LIGHT
LUGGAGE ROOM LIGHT
NCA WIRE
OFF TRUNK ROOM LIGHT
ON OFF
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RIGHT DOOR STEP LIGHT
RIGHT FRONT DOOR SWITCH (RIGHT "B" PILLAR)
RIGHT REAR DOOR SWITCH (RIGHT "C" PILLAR)
RIGHT VANITY MIRROR ILLUMINATION LIGHT
SEDAN
SPOT MAP LIGHT OVERHEAD CONSOLE
SPOT MAP LIGHT STEREO CAMERA COVER
W/ EYESIGHT
W/ EYESIGHT W/O EYESIGHT
W/O EYESIGHT
WAGON
WHT/RED WIRE
Go to component -> Courtesy lamps circuit (2 of 2) -> LEFT DOOR STEP LIGHT
Wiring diagram left door step light (2 of 2)
AUDIO
AUDIO CONNECTOR
BLK WIRE
BLU WIRE
BODY INTEGRATED UNIT
BRN WIRE
CLOCK
CONTROL MODULE
FROM MAIN FUSE BOX (M/B) (DIAGRAM 3 OF 6)
FUSE 14
FUSE, RELAY BOX (F/B) (LEFT KICK PANEL)
GRN/WHT WIRE
J/C
LEFT DOOR STEP LIGHT
LEFT PUDDLE LIGHT
LEFT VANITY MIRROR ILLUMINATION LIGHT
LUGGAGE ROOM LIGHT
NAVIGATION UNIT
NCA WIRE
OVERHEAD STEREO CONSOLE CAMERA (SPOT MAP COVER LIGHT) (SPOT MAP LIGHT)
REAR VIEW MIRROR (W/ REARVIEW DISPLAY, HOME LINK)
RED WIRE
REMOTE ENGINE
RIGHT DOOR STEP LIGHT
RIGHT PUDDLE LIGHT
RIGHT VANITY MIRROR ILLUMINATION LIGHT
ROOM LIGHT
SEDAN
TRUNK ROOM LIGHT
W/ EYESIGHT
W/O EYESIGHT
W/O TPMS W/ TPMS
WAGON
Go to component -> Power distribution circuit (6 of 6) -> LEFT DOOR STEP LIGHT
