Subaru Legacy BM/BR facelift (2012-2014) fuse 38 Wiring diagram
This page shows the only wiring diagram for the component.fuse 38, which is found in the car Subaru Legacy BM/BR facelift (2012-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram fuse 38 (1 of 1)
BLK/YEL WIRE
BLU WIRE
BLU/WHT WIRE
BRN WIRE
BRN/WHT WIRE
COMPUTER DATA LINES SYSTEM
DOWN
FUSE 12
FUSE 38
FUSE 5
FUSE 7
FUSE 8
FUSE, RELAY BOX (F/B) (LEFT KICK PANEL)
GRN/RED WIRE
GRN/WHT WIRE
GRN/YEL WIRE
HOT AT ALL TIMES
HOT AT ALL TIMES MAIN FUSE BOX (M/B) FUSE 1 (LEFT SIDE OF ENGINE COMPT)
HOT IN ON OR START
J/C
MANUAL MODE SWITCH AT SELECT LEVER
NCA WIRE
ORG/BLK WIRE
PADDLE SHIFT SWITCH
RED WIRE
RED/BLU WIRE
ROLL CONNECTOR (LEFT SIDE OF DASH)
SECONDARY PRESSURE SENSOR (TOP FRONT OF CVT TRANSMISSION)
STOP LIGHT, BRAKE SWITCH (LEFT SIDE OF DASH)
TCM (LEFT SIDE OF DASH)
WHT WIRE
WHT/BLU WIRE
WHT/GRN WIRE
WHT/RED WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> Cvt circuit (1 of 2) -> FUSE 38
