Subaru Legacy BM/BR facelift (2012-2014) fuse 21 Wiring diagrams
This page contains all the electrical diagrams for the component. fuse 21, in which he is found in the car Subaru Legacy BM/BR facelift (2012-2014). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram fuse 21 (1 of 3)
BATTERY
BLK WIRE
BLK/BLU WIRE
BLK/GRN WIRE
BLK/WHT WIRE
BLK/YEL WIRE
CLUTCH STROKE SENSOR (CLUTCH START SWITCH) (LEFT SIDE OF DASH)
CVT
CVT M/T
ECM (RIGHT SIDE OF DASH)
FUSE 21
FUSE, RELAY BOX (F/B) (LEFT KICK PANEL)
GRN/BLK WIRE
IGNITION SWITCH
INHIBITOR SWITCH (TOP OF TRANSMISSION)
M/T
MAIN FUSE BOX (M/B) MAIN SBF FUSE (LEFT SIDE OF ENGINE COMPT)
NCA WIRE
NEUTRAL POSITION SWITCH
OFF ON
SBF-5 FUSE
STARTER MOTOR
STARTER RELAY FUSE, RELAY BOX (F/B)
WHT WIRE
WHT/BLK (OR WHT) WIRE
WHT/BLK WIRE
WHT/BLU WIRE
WHT/GRN WIRE
Go to component -> 2.5l, starting circuit, without push button start -> FUSE 21
Wiring diagram fuse 21 (2 of 3)
BATTERY
BLK WIRE
BLK/BLU WIRE
BLU WIRE
COMPUTER DATA LINES SYSTEM
ECM (RIGHT SIDE OF DASH)
FUSE 21
FUSE, RELAY BOX (F/B) (LEFT KICK PANEL)
GB-6 (LEFT KICK PANEL)
GRN/BLK WIRE
IGNITION SWITCH
INHIBITOR RELAY
KEYLESS ACCESS CONTROL MODULE (CENTER FRONT OF LUGGAGE COMPT)
LT BLU WIRE
MAIN FUSE BOX (M/B) MAIN SBF FUSE (LEFT SIDE OF ENGINE COMPT)
NCA WIRE
OFF ON
PUSH BUTTON IGNITION SWITCH
RED WIRE
SBF-5 FUSE
STARTER MOTOR
STARTER RELAY RELAY HOLDER (RIGHT END OF DASH)
TCM (LEFT SIDE OF DASH)
WHT WIRE
WHT/BLK WIRE
WHT/BLU WIRE
WHT/ORG WIRE
Go to component -> 3.6l, starting circuit, with push button start -> FUSE 21
Wiring diagram fuse 21 (3 of 3)
2.5L
2.5L 27 30 3.6L STARTER RELAY FUSE, RELAY BOX (F/B) (LEFT KICK PANEL) ECM
A/C BODY CONTROL INTEGRATED MODULE UNIT
A/C CONTROL MODULE
A/C CONTROL PANEL
AUTOMATIC A/C MANUAL A/C 5 7
BLK WIRE
BLU WIRE
BODY INTEGRATED UNIT
BRN WIRE
CLUTCH STROKE INHIBITOR SENSOR RELAY (CLUTCH START SWITCH)
COMBINATION CLOCK METER
CVT A/T A/T
CVT M/T
FROM ACCESSORY RELAY (DIAGRAM 4 OF 6)
FROM MAIN FUSE BOX (M/B) (DIAGRAM 1 OF 6)
FUEL PUMP RELAY
FUSE 21
FUSE 24
FUSE 31
FUSE, RELAY BOX (F/B) (LEFT KICK PANEL)
GRN WIRE
IGNITION SWITCH
J/C
KEYLESS ACCESS CONTROL MODULE
NAVIGATION AUDIO UNIT
OFF
OFF ON
ORG/ WIRE
RED WIRE
RELAY FUSE FUSE 12
STARTER RELAY RELAY HOLDER (RIGHT END OF DASH)
TCM
TO ACCESSORY RELAY (DIAGRAM 4 OF 6)
TO FUSE 25 (DIAGRAM 3 OF 6)
TO FUSE 4 (DIAGRAM 5 OF 6)
TO FUSE, RELAY BOX (F/B) (DIAGRAM 3 OF 6)
TO FUSE, RELAY BOX (F/B) (DIAGRAM 4 OF 6)
W/ PUSH BUTTON START W/O PUSH BUTTON START
W/O W/ NAVIGATION NAVIGATION
WHT WIRE
WHT/BLU WIRE
YEL WIRE
Go to component -> Power distribution circuit (2 of 6) -> FUSE 21
