Subaru Legacy BM/BR facelift (2012-2014) down lifter switch up Wiring diagram

BACKWARD SLIDE SWITCH FORWARD BACKWARD TILT SWITCH UP BLK WIRE BLK/BRN WIRE BLK/WHT WIRE BLK/YEL WIRE BLU WIRE BLU/RED WIRE BLU/WHT WIRE BLU/YEL WIRE BRN WIRE DOWN DOWN LIFTER SWITCH UP GB-9 (SEDAN: CENTER OF REAR PARCEL SHELF) (WAGON: LEFT "D" PILLAR) GRN WIRE GRN/BLK WIRE GRN/YEL WIRE GRY WIRE GRY/BLK WIRE HOT AT ALL TIMES LEFT POWER SEAT LEFT POWER SEAT SWITCH LIFTER MOTOR LIFTER PULSE LT BLU WIRE LT GRN WIRE LT GRN/BLK WIRE LUMBER MOTOR LUMBER SWITCH MAIN FUSE BOX (M/B) (LEFT SIDE OF ENGINE COMPT) NCA WIRE PNK WIRE PNK/BLK WIRE POWER SEAT CM RECLINING MOTOR RECLINING PULSE RECLINING SWITCH FORWARD RED WIRE RED/WHT WIRE SBF-11 FUSE SLIDE MOTOR SLIDE PULSE TILT MOTOR TILT PULSE VIO WIRE VIO/WHT WIRE WHT WIRE WHT/BLK WIRE WHT/GRN WIRE WHT/RED WIRE YEL WIRE YEL/BLK WIRE
