Subaru Legacy BM/BR facelift (2012-2014) back-up light switch Wiring diagrams
This page contains all the electrical diagrams for the component. back-up light switch, in which he is found in the car Subaru Legacy BM/BR facelift (2012-2014). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram back-up light switch (1 of 2)
A/T
BACK-UP LIGHT RELAY
BACK-UP LIGHT SWITCH
BLK WIRE
BLK/YEL WIRE
BLU WIRE
BLU/ORG WIRE
BLU/RED WIRE
BLU/YEL WIRE
BRN/RED WIRE
BRN/YEL WIRE
CVT
EXTERIOR LIGHTS
FUSE 14
FUSE 18
FUSE 4
FUSE, RELAY BOX (F/B) (LEFT KICK PANEL)
GB-9 (LEGACY: CENTER OF REAR PARCEL SHELF) (OUTBACK: LEFT "D" PILLAR)
GRN/BLU WIRE
GRN/WHT WIRE
GRN/YEL WIRE
HOT AT ALL TIMES
HOT IN ON OR START
INHIBITOR SWITCH (TOP OF TRANSMISSION)
M/T
NCA WIRE
REARVIEW CAMERA
REARVIEW MIRROR)
RED WIRE
SYSTEM
WHT WIRE
WHT/BLK WIRE
WHT/BLU WIRE
YEL WIRE
Go to component -> Automatic day/night mirror circuit, with home link & rear camera display -> BACK-UP LIGHT SWITCH
Wiring diagram back-up light switch (2 of 2)
A/T
BACK-UP LIGHT SWITCH
BLK WIRE
BLK/GRN WIRE
BLU WIRE
BRN WIRE
BRN/RED WIRE
BRN/YEL WIRE
COMPUTER DATA LINES SYSTEM
CVT
FUSE 18
FUSE 6
FUSE, RELAY BOX (F/B) (LEFT KICK PANEL)
GB-5 (RIGHT KICK PANEL)
GRN WIRE
GRN/BLU WIRE
HOT W/ ACCESSORY RELAY ENERGIZED
INHIBITOR SWITCH (TOP OF TRANSMISSION)
M/T
NCA WIRE
REARVIEW MIRROR)
RED WIRE
RELAY ENERGIZED
TCM (LEFT SIDE OF DASH)
WHT/BLK WIRE
YEL WIRE
YEL/BLU WIRE
Go to component -> Automatic day/night mirror circuit, without home link -> BACK-UP LIGHT SWITCH
