Subaru Legacy BM/BR (2009-2012) right/ retractable left motor motor Wiring diagram
This page shows the only wiring diagram for the component.right/ retractable left motor motor, which is found in the car Subaru Legacy BM/BR (2009-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right/ retractable left motor motor (1 of 1)
BLK WIRE
BLU WIRE
CHANGE OVER SWITCH
DEFOGGER SYSTEM
FUSE 6
FUSE, RELAY BOX (F/B) (LEFT KICK PANEL)
GB-6 (LEFT KICK PANEL)
GRN WIRE
HOT W/ ACCESSORY RELAY ENERGIZED
LEFT OUTER MIRROR ASSEMBLY
LEFT/ UP/ RIGHT DOWN MOTOR MOTOR
MIRROR HEATER
MIRROR HEATER RETRACTABLE MOTOR
NCA WIRE
RED WIRE
REMOTE CONTROL MIRROR SWITCH
REMOTE CONTROL SWITCH
RETRACTION SWITCH
RIGHT OUTER MIRROR ASSEMBLY
RIGHT/ RETRACTABLE LEFT MOTOR MOTOR
UP/ DOWN MOTOR
WHT WIRE
YEL WIRE
Go to component -> Power mirror circuit, with retractable outer mirror -> RIGHT/ RETRACTABLE LEFT MOTOR MOTOR
