Subaru Legacy BM/BR (2009-2012) mirror heater relay Wiring diagrams
This page contains all the electrical diagrams for the component. mirror heater relay, in which he is found in the car Subaru Legacy BM/BR (2009-2012). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram mirror heater relay (1 of 3)
A/C CONTROL PANEL
AUTOMATIC A/C
BLK WIRE
BLK/BLU WIRE
BLK/PNK WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU/RED WIRE
ECM IGNITION IGNITION COIL COIL
EPB CONTROL MODULE
FROM
FROM GB-5 (DIAGRAM 1 OF 3)
FRONT ACCESSORY
FRONT POWER WINDOW SUB SWITCH RIGHT OUTER MIRROR ASSEMBLY
GB-10 (BASE OF LEFT "B" PILLAR)
GB-6 (LEFT KICK PANEL)
GB-9 (SEDAN: CENTER OF REAR PARCEL SHELF) (WAGON: LEFT "D" PILLAR)
GE (3.6L) (LEFT REAR OF ENGINE)
GLOVE BOX ILLUMINATION LIGHT
GRN WIRE
IGNITION IGNITION IGNITION IGNITION COIL COIL COIL COIL
KNOCK SENSOR 2 SHIELD
LEFT
LEFT KEYLESS REAR ENTRY DOOR CONTROL SWITCH MODULE
LEFT OUTER MIRROR ASSEMBLY
LEFT POWER SEAT
LEFT REAR COMBINATION SWITCH
LEFT REAR POWER WINDOW SUB SWITCH
LEFT VANITY MIRROR ILLUMINATION LIGHT
LOWER COVER SWITCH (TRUNK LID OPENER)
LOWER COVER SWITCH (VDC OFF)
MIRROR HEATER RELAY
NAVIGATION UNIT SHIELD
NCA WIRE
PASSENGER'S DOOR LOCK SPOT MIRROR SWITCH MAP LIGHT
REAR ACCESSORY POWER SUPPLY SOCKET (CONSOLE BOX)
REAR VIEW
REARVIEW CAMERA SHIELD
RED WIRE
REMOTE CONTROL MIRROR SWITCH
RIGHT OUTER MIRROR WIPER IMPACT POWER ASSEMBLY DEICER SENSOR SUPPLY SOCKET
RIGHT VANITY MIRROR ILLUMINATION LIGHT ROOM LIGHT
SEAT HEATER RELAY
SEDAN
SUNROOF MOTOR ASSEMBLY,
TURN SIGNAL POWER FRONT WINDOW POWER HAZARD MAIN WINDOW MODULE SWITCH MOTOR
W/ RETRACTRABLE MIRROR W/O RETRACTRABLE MIRROR MANUAL A/C
WHT/RED WIRE
YEL WIRE
Go to component -> Ground distribution circuit (2 of 3) -> MIRROR HEATER RELAY
Wiring diagram mirror heater relay (2 of 3)
