Subaru Legacy BM/BR (2009-2012) fuel temperature fuel pump sensor Wiring diagram

BLK WIRE BLK/BLU WIRE BLK/GRN WIRE BLK/WHT WIRE BLK/YEL WIRE BLU WIRE BRN WIRE BRN/WHT WIRE FUEL TEMPERATURE FUEL PUMP SENSOR GB-7 (SEDAN: CENTER FRONT OF LUGGAGE COMPT) (WAGON: RIGHT QUARTERPANEL) GE (LEFT REAR OF ENGINE) GRN WIRE GRN/ORG WIRE GRN/RED WIRE GRN/WHT WIRE GRN/YEL WIRE KNOCK SENSOR (TOP REAR OF ENGINE) LEFT INTAKE CAMSHAFT POSITION SENSOR (LEFT REAR OF ENGINE) LEFT TUMBLE GENERATOR VALVE ASSEMBLY (LEFT REAR OF ENGINE) LT GRN WIRE LT GRN/RED WIRE NCA WIRE OIL LEVEL SWITCH (LEFT REAR OF ENGINE) ORG/ WIRE PNK WIRE PNK/BLU WIRE PURGE CONTROL SOLENOID VALVE 1 (TOP FRONT OF ENGINE) PURGE CONTROL SOLENOID VALVE 2 (RIGHT REAR OF ENGINE) RED WIRE RED/BLK WIRE RED/BLU WIRE RIGHT TUMBLE GENERATOR VALVE ASSEMBLY (RIGHT REAR OF ENGINE) WHT WIRE WHT/BLK WIRE WHT/BLU WIRE WHT/GRN WIRE WHT/RED WIRE YEL WIRE YEL/BLK WIRE YEL/BLU WIRE YEL/GRN WIRE YEL/RED WIRE YEL/WHT WIRE
