Subaru Legacy BM/BR (2009-2012) auxiliary input navigation audio terminal unit Wiring diagram
This page shows the only wiring diagram for the component.auxiliary input navigation audio terminal unit, which is found in the car Subaru Legacy BM/BR (2009-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram auxiliary input navigation audio terminal unit (1 of 1)
2.5L NON- TURBO
A/C BODY CONTROL INTEGRATED MODULE UNIT
A/C CONTROL PANEL
A/T
AIR BAG CONTROL MODULE
AT SELECT LEVER
AUDIO BRACKET GROUND
AUTOMATIC A/C
AUXILIARY INPUT NAVIGATION AUDIO TERMINAL UNIT
BLK WIRE
BLK/GRN WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BODY INTEGRATED UNIT
BRAKE FLUID LEVEL SWITCH
CLOCK
COMBINATION SWITCH COMBINATION (LIGHTING) SWITCH (WIPER)
COMPRESSOR SOLENOID
CONTROL MODULE
DAYTIME RUNNING LIGHT (3.6L) RESISTOR RADIATOR FAN CONTROL UNIT
FRONT WIPER MOTOR
GB-5 (RIGHT KICK PANEL)
GR (LEFT SIDE OF CENTER CONSOLE)
GRN WIRE
HOOD SWITCH
KEYLESS BUZZER
LEFT FRONT COMBINATION LIGHT
LEFT FRONT FOG LIGHT
M/T
MAIN FAN MOTOR
MAIN FAN RELAY 2
MAIN FUSE BLOCK (M/B) POWER WINDOW RELAY
NAVIGATION UNIT
RED WIRE
REMOTE ENGINE
RIGHT FRONT COMBINATION LIGHT
RIGHT FRONT FOG LIGHT
ROLL CONNECTOR
SECURITY CONTROL MODULE
STEERING ANGLE SENSOR
TCM
TO GB-6 (DIAGRAM 2 OF 3)
W/O DAYTIME RUNNING LIGHT
W/O DAYTIME RUNNING LIGHT W/ DAYTIME RUNNING LIGHT MANUAL A/C
Go to component -> Ground distribution circuit (1 of 3) -> AUXILIARY INPUT NAVIGATION AUDIO TERMINAL UNIT
