Subaru Legacy BL/BP facelift (2006-2009) Shift interlock circuit

AT SELECT LEVER BLK WIRE BLK/WHT WIRE BLK/YEL WIRE BLU WIRE BLU/RED WIRE BLU/YEL WIRE BODY INTEGRATED UNIT (CENTER OF DASH) BRN WIRE BRN/WHT WIRE COMPUTER DATA LINES SYSTEM FUSE FUSE 12 FUSE 31 FUSE 7 FUSE, RELAY FUSE 8 BOX (F/B) (LEFT END OF DASH) GB-4 (AT REAR OF ENGINE COMPT) GB-7 (RIGHT SIDE OF DASH) GRN WIRE GRN/RED WIRE HOT AT ALL TIMES HOT IN ON OR ACC HOT IN ON OR START KEY LOCK SOLENOID, KEY WARNING SWITCH MAIN FUSE BOX FUSE 14 (LEFT SIDE FUSE 8 OF ENGINE COMPT) RED WIRE RELAY BLOCK STOP, BRAKE SWITCH (W/ CRUISE CONTROL: ON BRAKE PEDAL BRACKET) WHT WIRE WHT/BLK WIRE WHT/BLU WIRE YEL WIRE YEL/RED WIRE
