Instrument illumination circuit for Subaru Legacy BL/BP facelift (2006-2009)

A/C CONTROL PANEL (MANUAL A/C) A/T INDICATOR ILLUMINATION LIGHT SATELLITE SWITCH ILLUMINATION LIGHT (3.0L) AUDIO BLK WIRE BLK/WHT WIRE BLK/YEL WIRE BLU WIRE BLU/GRN WIRE BLU/RED WIRE BODY INTEGRATED UNIT (CENTER OF DASH) CLOCK COMBINATION METER COMBINATION SWITCH LIGHT SWITCH FUSE 12 FUSE 7 FUSE 15 FUSE 8 FUSE SBF 8 FUSE, RELAY BOX (F/B) FUSE 16 (LEFT END OF DASH) GB-3 GB-4 (AT REAR OF ENGINE COMPT) GB-6 (CENTER OF DASH) GLOVE BOX ILLUMINATION LIGHT GRN WIRE GRN/RED WIRE GRN/YEL WIRE GROUND JOINT CONNECTOR GRY WIRE HAZARD SWITCH HEAD OFF TAIL HOT AT ALL TIMES HOT IN ON OR START ILLUMINATION CONTROL MODULE (LEFT SIDE JOINT CONNECTOR LT BLU WIRE MAIN FUSE BOX (LEFT SIDE OF ENGINE COMPARTMENT) NCA WIRE OF DASH) PUSH SWITCH RED WIRE REMOTE CONTROL MIRROR SWITCH SEAT HEATER SWITCH SI- DRIVE SELE- CTOR TAIL, ILLUMINATION RELAY TV MONITOR VIO WIRE WHT WIRE WHT/BLU WIRE
