Manual a/c circuit for Subaru Legacy BL/BP facelift (2006-2009)

A/C CONTROL PANEL AMBIENT SENSOR (BEHIND LEFT SIDE OF FRONT BUMPER) BLK WIRE BLK/BLU WIRE BLK/RED WIRE BLK/WHT WIRE BLK/YEL WIRE BLOWER FAN MOTOR (BEHIND RIGHT SIDE OF DASH) BLOWER FAN RELAY (IN RELAY BLOCK) BLOWER FAN RESISTOR BLOWER FAN SWITCH BLU WIRE BLU/BLK WIRE BLU/GRN WIRE BLU/ORG WIRE BLU/PNK WIRE BLU/WHT WIRE BLU/YEL WIRE BODY INTEGRATED UNIT (CENTER OF DASH) BRN/YEL WIRE DEFOGGER SYSTEM FRESH/RECIRC ACTUATOR (ON RIGHT SIDE OF UPPER INTAKE UNIT CASE) FUSE 22 FUSE 26 FUSE 27 FUSE 28 FUSE, RELAY BOX (F/B) (LEFT END OF DASH) GB-3 GB-7 (RIGHT SIDE OF DASH) GRN/BLK WIRE GRN/BLU WIRE GRN/ORG WIRE GRN/YEL WIRE GROUND J/C HOT AT ALL TIMES HOT IN ON OR START LT BLU WIRE LT GRN/WHT WIRE MODE ACTUATOR ORG/ WIRE PNK/GRN WIRE PRESSURE SWITCH (ON A/C RECEIVER-DRIER) RED/BLK WIRE RED/BLU WIRE RED/YEL WIRE THROUGH J/C VIO WIRE VIO/YEL WIRE YEL WIRE YEL/BLK WIRE

A/C RELAY BLK WIRE BLK/WHT WIRE BLU/GRN WIRE BLU/ORG WIRE BLU/RED WIRE BLU/WHT WIRE BRN/WHT WIRE ENGINE COMPT) ENGINE CONTROL MODULE (BEHIND RIGHT SIDE OF DASH) EVAPORATOR THERMO SWITCH (BEHIND RIGHT SIDE OF DASH) FUSE 3 GB-2 (AT LEFT FRONT OF ENGINE COMPT) GB-4 (AT REAR OF ENGINE COMPT) GRN/BLK WIRE GRN/BLU WIRE GRN/ORG WIRE HOT AT ALL TIMES MAGNET CLUTCH MAIN FAN MOTOR (LEFT FRONT OF ENGINE COMPT) MAIN FAN RELAY 1 MAIN FAN RELAY 2 MAIN FUSE BOX (M/B) (LEFT SIDE OF ENGINE COMPT) NCA WIRE ORG/ WIRE RED WIRE RED/BLU WIRE RED/WHT WIRE RELAY HOLDER (LEFT SIDE OF ENGINE COMPT) SUB FAN MOTOR (RIGHT FRONT OF SUB FAN RELAY THROUGH J/C VIO/YEL WIRE WHT/RED WIRE YEL WIRE YEL/BLK WIRE YEL/GRN WIRE
