Subaru Legacy BL/BP facelift (2006-2009) tcs off ind/ vdc warning ind Wiring diagram

ABS WARNING LIGHT IND BLK WIRE BLK/YEL WIRE BLU WIRE BRN WIRE BRN/RED WIRE BRN/WHT WIRE CAN JOINT CONNECTOR CAN TRANSCEIVER, RECEIVER COMBINATION METER COMPUTER DATA LINES SYSTEM DATA LINK CONNECTOR (UNDER LEFT SIDE OF DASH) DRIVER CIRCUIT FUSE FUSE 1 FUSE 33 FUSE 5 FUSE, RELAY BOX FUSE 8 (LEFT END OF DASH) GB-3 GB-4 (AT REAR OF ENGINE COMPT) GB-7 (RIGHT SIDE OF DASH) GB-7 (RIGHT SIDE OF DASH) GB-3 GRN WIRE GRN/BLK WIRE GRN/ORG WIRE GRN/YEL WIRE GV (RIGHT SIDE OF ENGINE COMPT) HOT AT ALL TIMES HOT IN ON OR START JOINT JOINT CONNECTOR LEFT FRONT ABS WHEEL SPEED SENSOR (ON LEFT FRONT KNUCKLE SPINDLE ASSEMBLY) LEFT REAR ABS WHEEL SPEED SENSOR (ON LEFT REAR KNUCKLE SPINDLE ASSEMBLY) LT GRN WIRE LT GRN/BLK WIRE LT GRN/RED WIRE MAIN FUSE BOX (LEFT SIDE OF ENGINE COMPT) MICRO COMPUTER MOTOR RELAY NCA WIRE OF DASH) ORG/ WIRE PARKING BRAKE/BRAKE FLUID LEVEL WARNING LIGHT IND PNK WIRE PRIMARY CUT RR OUT RR IN RL OUT RL IN FR OUT FR IN FL OUT FL IN PRIMARY SUCTION PUMP MOTOR PUSH SWITCH (VDC OFF SWITCH) RED WIRE RED/YEL WIRE RELAY BLOCK REVERSE CIRCUIT RIGHT FRONT ABS WHEEL SPEED SENSOR (ON RIGHT FRONT KNUCKLE SPINDLE ASSEMBLY) RIGHT REAR ABS WHEEL SPEED SENSOR (ON RIGHT REAR KNUCKLE SPINDLE ASSEMBLY) SBF-1 FUSE SECONDARY CUT SECONDARY SUCTION SOLENOID VALVE STEERING ANGLE SENSOR (CENTER OF DASH) STOP LIGHT SWITCH (W/ CRUISE CONTROL: ON BRAKE PEDAL BRACKET) TCS OFF IND/ VDC WARNING IND VALVE RELAY VDC CONTROL MODULE (AT RIGHT REAR CORNER OF ENGINE COMPT) VDC OPERATION IND VIO WIRE VIO/RED WIRE WHT WIRE WHT/BLU WIRE WHT/RED WIRE YAW RATE SENSOR (BELOW CENTER CONSOLE)
