Subaru Legacy BL/BP facelift (2006-2009) sub fan motor (right front of Wiring diagrams
This page contains all the electrical diagrams for the component. sub fan motor (right front of, in which he is found in the car Subaru Legacy BL/BP facelift (2006-2009). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram sub fan motor (right front of (1 of 2)
2.5L
2.5L TURBO 2.5L
A/C RELAY
BLK WIRE
BLK/WHT WIRE
BLU/GRN WIRE
BLU/ORG WIRE
BLU/RED WIRE
BRN/WHT WIRE
ENGINE COMPT)
ENGINE CONTROL MODULE (BEHIND RIGHT SIDE OF DASH)
FUSE 3
GB-2 (AT LEFT FRONT OF ENGINE COMPT)
GB-4 (AT REAR OF ENGINE COMPT)
GRN/BLK WIRE
GRN/BLU WIRE
GRN/ORG WIRE
HOT AT ALL TIMES
MAGNET CLUTCH
MAIN FAN MOTOR (LEFT FRONT OF ENGINE COMPT)
MAIN FAN RELAY 1
MAIN FAN RELAY 2
MAIN FUSE BOX (M/B) (LEFT SIDE OF ENGINE COMPT)
NCA WIRE
RED WIRE
RED/BLU WIRE
RED/WHT WIRE
RELAY HOLDER (LEFT SIDE OF ENGINE COMPT)
SUB FAN MOTOR (RIGHT FRONT OF
SUB FAN RELAY
THROUGH J/C
VIO/YEL WIRE
WHT/RED WIRE
YEL WIRE
YEL/BLK WIRE
YEL/GRN WIRE
Go to component -> Automatic a/c circuit (3 of 3) -> SUB FAN MOTOR (RIGHT FRONT OF
