Subaru Legacy BL/BP facelift (2006-2009) navigation control unit audio clock rear wiper motor Wiring diagram
This page shows the only wiring diagram for the component.navigation control unit audio clock rear wiper motor, which is found in the car Subaru Legacy BL/BP facelift (2006-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram navigation control unit audio clock rear wiper motor (1 of 1)
A/T
AIR BAG CONTROL MODULE
AUTO A/C CONTROL MODULE
BLK WIRE
BLU WIRE
BODY INTEGRATED UNIT TCM 4 A/T MODEL 5 A/T MODEL
BRN WIRE
COMBINATION METER
COMBINATION SWITCH
ECM CLUTCH SWITCH (M/T)
FROM FUSE, RELAY BOX ACCESSORY RELAY (DIAGRAM 4 OF 5)
FROM MAIN FUSE BOX SBF-6 (DIAGRAM 1 OF 5)
FRONT WIPER SWITCH FRONT WASHER MOTOR FRONT WIPER MOTOR
FUEL PUMP RELAY IGNITION COILS (2.5L TURBO) P-VIGN RELAY (5 A/T MODEL)
FUSE 12
FUSE 21
FUSE 24 FUSE 30 FUSE 23
FUSE 31
FUSE 5 RELAY
FUSE, RELAY BOX (F/B) (LEFT END OF DASH)
GRN WIRE
IGNITION
IGNITION SWITCH
INHIBITOR RELAY (EXCEPT 2.5L)
NAVIGATION CONTROL UNIT AUDIO CLOCK REAR WIPER MOTOR
OFF
REAR WASHER MOTOR
REAR WHEEL SPEED SENSOR (4 A/T MODEL)
RED WIRE
STARTER RELAY
TO FUSE, RELAY BOX ACCESSORY RELAY (DIAGRAM 4 OF 5)
TO FUSE, RELAY BOX FUSE 22 (DIAGRAM 3 OF 5)
TO FUSE, RELAY BOX FUSE 25 (DIAGRAM 3 OF 5)
TV MONITOR
WAGON
WHT WIRE
WHT/BLU WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> Power distribution circuit (2 of 5) -> NAVIGATION CONTROL UNIT AUDIO CLOCK REAR WIPER MOTOR
