Subaru Legacy BL/BP facelift (2006-2009) impact sensor Wiring diagrams
This page contains all the electrical diagrams for the component. impact sensor, in which he is found in the car Subaru Legacy BL/BP facelift (2006-2009). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram impact sensor (1 of 2)
ABS CONTROL MODULE
AUDIO CLOCK KEYLESS ENTRY CONTROL MODULE
BATTERY
BLK WIRE
BLOWER FAN RELAY
BLU WIRE
BLU/RED WIRE
BODY INTEGRATED UNIT AUTO A/C CONTROL MODULE
BODY INTEGRATED UNIT ROOM LIGHT HOME LINK (IF EQUIPPED)
DASH)
FRONT FOG LIGHT RELAY
FUSE 1
FUSE 16
FUSE 17
FUSE 27
FUSE 28
FUSE 29
FUSE 3 (2.5L)
FUSE 5
FUSE 7 4 OF 5)
FUSE 8
FUSE 9
FUSE, RELAY BOX (F/B) (LEFT END OF
GENERATOR
GRN WIRE
IMPACT SENSOR
JOINT CONNECTOR (ILLUMINATION, BACK-UP LIGHT)
LUGGAGE ROOM LIGHT (WAGON) TRUNK ROOM LIGHT (SEDAN) NAVIGATION CONTROL UNIT
MAIN SBF FUSE
MIRROR WIPER DEICER RELAY HEATER RELAY (W/ MIRROR HEATER)
NCA WIRE
RED WIRE
RELAY HOLDER (LEFT SIDE OF ENGINE COMPT)
RIGHT STEP LIGHT LEFT STEP LIGHT
SBF-1 FUSE
SBF-2 FUSE
SBF-3 FUSE
SBF-6 FUSE
SBF-8 FUSE
SEAT HEATER RELAY
SPOT MAP LIGHT
STARTER MOTOR
STOP LIGHT, BRAKE SWITCH
SUB FAN RELAY
TO FUSE, RELAY BOX ACCESSORY RELAY (DIAGRAM
TO IGNITION SWITCH (DIAGRAM 2 OF 5)
TO MAIN FUSE BOX BOX TAIL, ILLUMINATION RELAY
TO MAIN FUSE BOX REAR DEFOGGER RELAY (DIAGRAM 3 OF 5)
TPM CONTROL MODULE COMBINATION METER
TRAILER CONNECTOR (WAGON)
TV MONITOR LIGHT
VDC CONTROL MODULE
WHT WIRE
WHT/BLU WIRE
YEL WIRE
Go to component -> Power distribution circuit (1 of 5) -> IMPACT SENSOR
Wiring diagram impact sensor (2 of 2)
1 2 (5 M/T) (6 M/T)
4 A/T
5 A/T
BACK-UP LIGHT RELAY
BACK-UP LIGHT SWITCH
BACK-UP LIGHT SWITCH (M/T)
BLK WIRE
BLU WIRE
BOX IGNITION 2 RELAY
CLOCK
CLUTCH SWITCH (M/T CRUISE)
DATA LINK CONNECTOR
DAY TIME RUNNING LIGHT RELAY
DAYTIME RUNNING LIGHT CONTROL MODULE
FROM FUSE, RELAY
FROM MAIN FUSE BOX (M/B) TAIL, ILLUMINATION RELAY (DIAGRAM 3 OF 5)
FUSE 11
FUSE 16
FUSE 18
FUSE 4
FUSE, RELAY BOX (F/B) (LEFT END OF DASH)
GRN WIRE
GRN/BLU WIRE
GRN/YEL WIRE
IMPACT SENSOR
INHIBITOR SWITCH
JOINT CONNECTOR (ILLUMINATION, BACK-UP LIGHT)
LEFT POWER SEAT (W/ SEAT POSITION MEMORY)
LT BLU WIRE
NAVIGATION CONTROL MODULE
NCA WIRE
NON TURBO
PARKING SWITCH
ROOL CONNECTOR
SATELLITE SWITCH (3.0L)
SEAT BELT, AIR BAG WARNING LIGHT
SEAT HEATER SWITCH
SUNROOF CONTROL MODULE STOP LIGHT, BRAKE SWITCH
SUNROOF SWITCH
SUNROOF TILT SWITCH
TPM CONTROL MODULE
TURBO
TURN SIGNAL, HAZARD MODULE
TV MONITOR
VIO WIRE
WHT WIRE
WIPER DEICER RELAY
YEL WIRE
Go to component -> Power distribution circuit (5 of 5) -> IMPACT SENSOR
