Subaru Legacy BL/BP facelift (2006-2009) front washer switch on Wiring diagram
This page shows the only wiring diagram for the component.front washer switch on, which is found in the car Subaru Legacy BL/BP facelift (2006-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram front washer switch on (1 of 1)
BLK WIRE
BLK/BLU WIRE
BODY INTEGRATED UNIT (CENTER OF DASH)
BRN/WHT WIRE
COMBINATION SWITCH
FRONT WASHER MOTOR (LEFT SIDE OF ENGINE COMPT, IN WASHER TANK)
FRONT WASHER SWITCH ON
FRONT WIPER MOTOR (ON LEFT WIPER SIDE OF MOTOR FIREWALL)
FRONT WIPER SWITCH
GB-4 (AT REAR OF ENGINE COMPT)
GRN WIRE
GRN/YEL WIRE
HI OFF
HI OFF HI INT INT LO LO
HOT IN ACC OR ON FUSE, FUSE 30 RELAY BLOCK (LEFT END OF DASH)
MIST SWITCH MIST
NCA WIRE
OFF
OFF HI INT LO LO
PC BOARD
RED/BLU WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> Front wiper/washer circuit -> FRONT WASHER SWITCH ON
