Subaru Legacy BL/BP facelift (2006-2009) engine coolant temp gauge speedo- meter Wiring diagram
This page shows the only wiring diagram for the component.engine coolant temp gauge speedo- meter, which is found in the car Subaru Legacy BL/BP facelift (2006-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram engine coolant temp gauge speedo- meter (1 of 1)
BLK WIRE
BLK/YEL WIRE
BLU WIRE
BRN/WHT WIRE
COMBINATION METER
DRAIN VALVE
DRIVE CIRCUIT
ENGINE COOLANT
ENGINE COOLANT TEMP GAUGE SPEEDO- METER
FUEL PUMP ASSEMBLY (IN FUEL TANK)
FUEL PUMP RELAY
FUEL TEMP SENSOR
FUSE 11
FUSE SBF-5
FUSE SBF-7
GB-3
GB-5 (RIGHT SIDE OF DASH)
GB-9 (SEDAN: AT TOP CENTER OF TRUNK) (WAGON: LEFT "D" PILLAR)
GRN WIRE
GRN/ORG WIRE
GRN/RED WIRE
GRN/YEL WIRE
GROUND JOINT CONNECTOR
HOT AT ALL TIMES
LT GRN WIRE
LT GRN/BLK WIRE
LT GRN/RED WIRE
M/T
MAIN FUSE BOX (M/B) (LEFT SIDE OF ENGINE COMPT) FUSE 13
MALFUNCTION IND LIGHT
MICRO COMPUTER
NCA WIRE
OIL PRESSURE WARNING IND
ONE STEP DIMMER CIRCUIT
ORG/WHT WIRE
PNK 10 11 WIRE
PNK WIRE
POWER CIRCUIT
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/WHT WIRE
SHIFT
SI-DRIVE SELECTOR (CONSOLE)
TACHO- METER
TEMP IND
UP IND
WHT WIRE
WHT/BLK WIRE
WHT/BLU WIRE
WHT/GRN WIRE
WHT/RED WIRE
WHT/YEL WIRE
YEL/BLU WIRE
YEL/GRN WIRE
Go to component -> Wiring diagram engine performance 2.5l turbo (2 of 5) -> ENGINE COOLANT TEMP GAUGE SPEEDO- METER
