Subaru Legacy BL/BP (2003-2006) valve relay Wiring diagram

ABS "G" SENSOR (BELOW CENTER CONSOLE) ABS CONTROL MODULE (RIGHT SIDE OF ENGINE COMPARTMENT) ABS INDICATOR LIGHT ABS MOTOR GROUND BLK WIRE BLK/RED WIRE BLU WIRE BLU/WHT WIRE BLU/YEL WIRE CHECK CONNECTOR (LEFT END OF OF DASH) COMBINATION METER FUSE 18 FUSE 5 FUSE 8 FUSE, RELAY BOX FUSE 16 (LEFT REAR OF ENGINE COMPARTMENT) FUSE/ RELAY BOX (LEFT REAR OF ENGINE COMPT) GB-2 (AT LEFT FRONT OF ENGINE COMPARTMENT) GB-3 (AT REAR OF ENGINE COMPT) GRN WIRE GRN/BLK WIRE GRN/WHT WIRE HOT AT ALL TIMES HOT AT ALL TIMES SBF HOLDER (LEFT SIDE OF ENGINE COMPT) SBF-7 FUSE HOT IN ON OR START IGNITION RELAY (IN RELAY BLOCK) IGNITION SWITCH LEFT FRONT ABS SENSOR (LEFT FRONT WHEEL) LEFT REAR ABS SENSOR (LEFT REAR WHEEL) LT GRN WIRE LT GRN/BLK WIRE LT GRN/RED WIRE LT GRN/YEL WIRE MAIN FUSE BOX (LEFT SIDE OF ENGINE COMPT) MOTOR RELAY NCA WIRE PICK-UP TURBO ENGINE PNK WIRE PUMP MOTOR RED WIRE RED/BLK WIRE RED/WHT WIRE RED/YEL WIRE RR OUT RR IN RL OUT RL IN FR OUT FR IN FL OUT FL IN SBF-5 FUSE SOLENOID VALVE STOPLIGHT SWITCH (ON BRAKE PEDAL BRACKET) TRANSMISSION CONTROL MODULE (BEHIND LEFT SIDE OF DASH) VALVE RELAY W/ CRUISE W/ LOW EMISSION W/O SPORT SHIFT W/ SPORT SHIFT W/O CRUISE W/O LOW EMISSION W/O SPORT SHIFT WHT WIRE WHT/BLK WIRE WHT/BLU WIRE WHT/RED WIRE YEL WIRE YEL/BLK WIRE
