Subaru Legacy BL/BP (2003-2006) right rear combination lamp right license plate light Wiring diagram
This page shows the only wiring diagram for the component.right rear combination lamp right license plate light, which is found in the car Subaru Legacy BL/BP (2003-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right rear combination lamp right license plate light (1 of 1)
BLK WIRE
BLK/BLU WIRE
BLK/GRN WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
BLU/YEL WIRE
BRN WIRE
BRN/RED WIRE
COMBINATION METER
COMBINATION SWITCH
ENGINE COMPT)
FUSE 10
FUSE 16
FUSE 5
FUSE 6
FUSE 7
FUSE, RELAY BOX (LEFT END OF DASH) FUSE 5
FUSE/ RELAY BOX (LEFT END OF DASH)
GB-1 (AT RIGHT FRONT OF ENGINE COMPT)
GB-3 (AT REAR OF ENGINE COMPT)
GB-7 (AT FRONT LEFT SIDE OF CENTER CONSOLE)
GRN WIRE
GRN/WHT WIRE
HAZARD SWITCH
HOT AT ALL TIMES
HOT IN ON OR START
IGNITION RELAY (IN RELAY BLOCK)
LEFT LICENSE PLATE LIGHT
LEFT REAR COMBINATION LAMP
LEFT TURN IND
LICENSE PLATE LIGHT
LIGHT SWITCH HEAD
LT GRN WIRE
LT GRN/BLK WIRE
MAIN FUSE BOX (LEFT SIDE OF
NCA WIRE
OFF
ON OFF
ON ON OFF
ORG/ WIRE
PARKING SWITCH OFF ON OFF PARK
RED WIRE
RIGHT FRONT CLEARANCE LIGHT
RIGHT FRONT TURN SIGNAL LIGHT (LOWER)
RIGHT FRONT TURN SIGNAL LIGHT (UPPER)
RIGHT REAR COMBINATION LAMP RIGHT LICENSE PLATE LIGHT
RIGHT REAR FINISHER LIGHT
RIGHT TURN IND
SBF-2 FUSE
SEDAN
SIDE OF DASH)
STOP LIGHT
STOP LIGHT TAIL LIGHT
TAIL, ILLUMINATION RELAY
TAIL- LIGHT
TURN LIGHT
TURN LIGHT TAIL- LIGHT STOP- LIGHT
TURN SIGNAL SWITCH
TURN SIGNAL, HAZARD MODULE (BEHIND LEFT
VIO WIRE
W/ CRUISE CONTROL
W/O CRUISE CONTROL
WAGON
WAGON SEDAN
WHT WIRE
WHT/BLK WIRE
WHT/BLU WIRE
WHT/GRN WIRE
YEL WIRE
Go to component -> Exterior lamps circuit -> RIGHT REAR COMBINATION LAMP RIGHT LICENSE PLATE LIGHT
