Subaru Legacy BL/BP (2003-2006) intermittent wiper module Wiring diagram
This page shows the only wiring diagram for the component.intermittent wiper module, which is found in the car Subaru Legacy BL/BP (2003-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram intermittent wiper module (1 of 1)
BLK WIRE
BLK/BLU WIRE
COMBINATION SWITCH
FRONT WASHER MOTOR (LEFT SIDE OF ENGINE COMPT, IN WASHER TANK)
FRONT WIPER LO HIGH MOTOR (ON LEFT WIPER MOTOR SIDE OF FIREWALL)
GB-3 (AT REAR OF ENGINE COMPT)
GRN/YEL WIRE
HI OFF
HOT IN ACC OR ON FUSE, FUSE 15 RELAY BOX (LEFT REAR OF ENGINE COMPT)
INTERMITTENT VOLUME
INTERMITTENT WIPER MODULE
LT GRN/RED WIRE
MIST OFF HI OFF MIST SWITCH INT LO
NCA WIRE
OFF
OFF HI INT LO LO
PARK
REAR WIPER CIRCUIT
RED/BLU WIRE
RUN WIRE
WASHER SWITCH
WIPER SWITCH
YEL WIRE
YEL/BLK WIRE
Go to component -> Front wiper/washer circuit -> INTERMITTENT WIPER MODULE
