Subaru Legacy BL/BP (2003-2006) high mounted stop light Wiring diagram
This page shows the only wiring diagram for the component.high mounted stop light, which is found in the car Subaru Legacy BL/BP (2003-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram high mounted stop light (1 of 1)
A/C PRESSURE SWITCH (3.0L) INHIBITOR SWITCH (A/T) MAIN RELAY
ABS CONTROL MODULE
AIR BAG CONTROL MODULE
ASHTRAY ILLUMI- NATION LIGHT
AT TOP CENTER OF TRUNK) FROM GROUND GB-3 (DIAGRAM
AUTO A/C CONTROL MODULE VDC OFF SWITCH
BLK WIRE
BLK/ WHT WIRE
BLOWER MOTOR RESISTOR (3.0L)
BRAKE FLUID LEVEL WARNING SWITCH
COMBINATION METER
COMPASS MIRROR
CRUISE CONTROL ACTUATOR A/T SELECT LEVER ILLUMI- NATION LIGHT
CRUISE CONTROL MODULE
DIAGNOSIS TERMINAL
FROM GROUND GB-3 (DIAGRAM
FRONT FOG LIGHT SWITCH
FRONT TILT LIMIT SWITCH
FRONT WIPER MOTOR
FUEL PUMP ASSEMBLY (W/O FPC)
FUEL PUMP CON- DENSER
FUEL PUMP CONTROL MODULE (W/ FPC)
FUEL PUMP CONTROL SOLENOID (W/ FPC)
GB-4 (AT REAR OF ENGINE COMPT) GB-6 (UNDER FRONT OF CENTER CONSOLE)
GB-5 (UNDER FRONT OF CENTER CONSOLE)
GB-7 (AT FRONT LEFT SIDE OF CENTER CONSOLE)
GB-9 (SEDAN:
GD (AT TOP CENTER OF TRUNK)
GLOVE BOX ILLUMI- NATION LIGHT WIPER DEICER SWITCH
GR (UNDER RIGHT FRONT OF CENTER CONSOLE)
HIGH MOUNTED STOP LIGHT
HIGH- MOUNTED STOP LIGHT (REAR SPOILER)
KEYLESS ENTRY CONTROL MODULE
LEFT FRONT DOOR SWITCH
LEFT REAR COMBINATION LIGHT
LEFT REAR DOOR SWITCH
LEFT REAR FINISHER LIGHT
LEFT SEAT HEATER
LEFT SEAT HEATER SWITCH
LICENSE PLATE LIGHT
MCINTOSH)
MODE ACTUATOR
MODE CONTROL PANEL (MANUAL A/C) FRONT ACCESSORY POWER SUPPLY SOCKET
POWER AMPLIFIER (W/
POWER SEAT
RADIO
REAR ACCESSORY POWER SUPPLY SOCKET (WAGON)
REAR DEFOGGER
REAR DEFOGGER (W/ CHOKE COIL)
REAR DEFOGGER (W/O CHOKE COIL) (SEDAN)
REAR DEFOGGER CONDENSER
REAR GATE LATCH SWITCH
REAR TILT LIMIT SWITCH
REAR WIPER INTER- MITTENT MODULE (WAGON)
REAR WIPER MOTOR
RECLINING SWITCH
RIGHT FRONT DOOR SWITCH
RIGHT LICENSE PLATE LIGHT LEFT LICENSE PLATE LIGHT
RIGHT REAR COMBINATION LIGHT
RIGHT REAR DOOR SWITCH
RIGHT REAR FINISHER LIGHT
RIGHT SEAT HEATER
RIGHT SEAT HEATER SWITCH
ROOM LIGHT MANUAL DOOR LOCK SWITCH
SEAT BELT SWITCH
SECURITY CONTROL MODULE
SEDAN
SHIFT MODEL)
SHIFT MODEL) (W/ VDC, W/ SPORT
SLIDE SWITCH
TRANSMISSION CONTROL MODULE
TRUNK ROOM LIGHT SWITCH
VEHICLE INTERFACE MODULE (W/ ON STAR)
WAGON
WHT BRN WIRE
WHT WIRE
WORKING LIGHT SWITCH
Go to component -> Ground distribution circuit (2 of 2) -> HIGH MOUNTED STOP LIGHT
