Subaru Legacy BL/BP (2003-2006) combination meter front accessory power supply socket illumination light Wiring diagram

2.5L: W/ LOW EMISSION 2.5L: W/O LOW EMISSION 25 24 (3.0L) (2.5L) 3.0L A/T A/T SELECT LEVER ILLUMINATION LIGHT INTEGRATED MODULE ABS CONTROL MODULE AIR CONDITIONING RELAY AIR CONDITIONING RELAY HOLDER AIRBAG CONTROL MODULE AUTO A/C CONTROL MODULE AUTO A/C CONTROL MODULE (A/T) BACK-UP LIGHT SWITCH (M/T) BLK WIRE BLK/WHT WIRE BLOWER MOTOR RELAY PRESSURE SWITCH BLU WIRE CLUTCH SWITCH COMBINATION METER FRONT ACCESSORY POWER SUPPLY SOCKET ILLUMINATION LIGHT CRUISE CONTROL MAIN SWITCH CRUISE CONTROL MAIN SWITCH ILLUMINATION LIGHT ASHTRAY ILLUMINATION LIGHT ENGINE CONTROL MODULE FAN RELAY (3.0L) FROM FUSE/ RELAY BOX FROM IGNITION SWITCH (DIAGRAM 2 OF 4) FRONT FOG LIGHT SWITCH ILLUMINATION LIGHT FUEL PUMP RELAY TRANSMISSION CONTROL MODULE FUSE 11 FUSE 12 FUSE 17 FUSE 18 FUSE 6 GLOVE BOX ILLUMINATION LIGHT GRN WIRE GRN/BLK WIRE GRN/RED WIRE HAZARD SWITCH ILLUMINATION LIGHT RADIO ILLUMINATION LIGHT IGNITION COIL 1 IGNITION COIL 2 IGNITION COIL 3 IGNITION COIL 4 IGNITION COIL 5 IGNITION COIL 6 IGNITION COIL, IGNITOR INHIBITOR SWITCH (A/T) CRUISE CONTROL MODULE LEFT SEAT HEATER SWITCH ILLUMINATION LIGHT LT GRN WIRE M/T MAIN FAN RELAY (2.5L) SUB FAN RELAY 1 (3.0L) MAIN FAN RELAY 1 MAIN FAN RELAY 2 MANUAL A/C AUTOMATIC A/C MODE CONTROL PANEL (M/T) MODE CONTROL PANEL ILLUMINATION LIGHT NCA WIRE PARKING SWITCH POWER WINDOW MAIN SWITCH ILLUMINATION LIGHT REAR DEFOGGER RELAY RED WIRE RIGHT SEAT HEATER SWITCH ILLUMINATION LIGHT SUB FAN RELAY SUB FAN RELAY 2 TAIL, ILLUMINATION RELAY VDC OFF SWITCH (SEDAN, WAGON) VEHICLE DYNAMIC CONTROL MODULE VIO WIRE WHT WIRE WIPER DEICER SWITCH ILLUMINATION LIGHT YEL WIRE
