Subaru Legacy BL/BP (2003-2006) check connector oxygen sensor heater relay Wiring diagram

16 1 (3.0L) (2.5L) 2.5L: W/ LOW EMISSION 2.5L: W/O LOW EMISSION ABS VDC AUTO A/C CONTROL MODULE BATTERY BLK WIRE BLK/RED WIRE BLOWER MOTOR RELAY ABS CONTROL MODULE VALVE RELAY BLU WIRE BLU/RED WIRE CHECK CONNECTOR OXYGEN SENSOR HEATER RELAY COMBINATION METER DASH) DATA LINK CONNECTOR ELECTRIC THROTTLE RELAY ENGINE CONTROL MODULE FUEL PUMP RELAY FUSE 1 FUSE 7 FUSE 13 FUSE 2 FUSE 3 FUSE 4 FUSE 5 FUSE 6 FUSE 7 FUSE 8 FUSE 8 FUSE 2 FUSE 9 FUSE, RELAY BOX (LEFT END OF GENERATOR GRN WIRE GRN/WHT WIRE HAZARD SWITCH HEADLIGHTS SYSTEM TO IGNITION SWITCH (DIAGRAM 2 OF 4) HORN RELAY IGNITION RELAY KEY WARNING SWITCH STOP, TURN MODULE HAZARD SWITCH KEYLESS ENTRY CONTROL MODULE LEFT HEADLIGHT RELAY MAIN RELAY NCA WIRE PARKING SWITCH POWER WINDOW CIRCUIT BREAKER POWER WINDOW RELAY POWER SEAT RADIO COMBINATION METER REAR DEFOGGER RELAY RED WIRE RED/YEL WIRE RELAY BOX RIGHT HEADLIGHT RELAY ROOM LIGHT SBF-1 FUSE SBF-3 FUSE FUSE 1 SBF-5 FUSE SBF-6 FUSE SECURITY CONTROL MODULE SECURITY CONTROL MODULE SECURITY HORN RELAY SPOT LIGHT STARTER MOTOR TO IGNITION SWITCH (DIAGRAM 2 OF 4) TO MAIN FUSE BOX SBF-4 (DIAGRAM 2 OF 4) TO MULTIPLE POWER SOCKET FUSE HOLDER (DIAGRAM 4 OF 4) TO TAIL, ILLUMINATION RELAY (DIAGRAM 3 OF 4) TRANSMISSION CONTROL MODULE VEHICLE SPEED SENSOR (M/T) W/ ONSTAR FRONT FOGLIGHT RELAY W/O ONSTAR W/ SPORT SHIFT WHT WIRE WHT/GRN WIRE WHT/RED WIRE YEL WIRE
