Anti-lock brake circuits, with traction control for Subaru Legacy BE/BH/BT (1998-2004)

BLK WIRE BLK/GRN WIRE BLK/WHT WIRE BLU WIRE BLU/BLK WIRE BLU/GRN WIRE BLU/ORG WIRE BLU/RED WIRE BRN WIRE BRN/RED WIRE BRN/YEL WIRE CHECK CONNECTOR (AT CENTER OF DASH) CRUISE CONTROL MODULE (BEHIND RIGHT SIDE OF DASH) DATA LINK CONNECTOR (AT CENTER OF DASH) DIAGNOSIS CONNECTOR (AT CENTER OF DASH) ENGINE CONTROL MODULE (BEHIND RIGHT SIDE OF DASH) FL INTLT VALVE FL OUTLT VALVE FR INTLT VALVE FR OUTLT VALVE GRN WIRE GRN/BLK WIRE GRN/BLU WIRE GRN/RED WIRE GRN/WHT WIRE HYDRAULIC MODULE (RIGHT SIDE OF ENGINE COMPT) LT GRN WIRE LT GRN/BLK WIRE LT GRN/RED WIRE LT GRN/YEL WIRE MOTOR RELAY NCA WIRE ORG/ WIRE ORG/BLK WIRE ORG/WHT WIRE PNK WIRE PRI CUT VALVE PRI PRESS SEN PRI SUCT VALVE PUMP MOTOR RED WIRE RED/BLK WIRE RED/BLU WIRE RED/GRN WIRE RED/WHT WIRE RED/YEL WIRE RELAY BOX (BEHIND LEFT SIDE OF DASH) RL INTLT VALVE RL OUTLT VALVE RR INTLT VALVE RR OUTLT VALVE SEC CUT VALVE SEC PRESS SEN SEC SUCT VALVE VALVE COM VALVE RELAY VDC CONTROL MODULE (LEFT REAR OF ENGINE COMPT) WHT WIRE WHT/BLK WIRE WHT/BLU WIRE WHT/GRN WIRE WHT/RED WIRE YEL WIRE YEL/BLK WIRE YEL/GRN WIRE YEL/WHT WIRE

1 2 PNK WIRE ABS WARNING LIGHT BLK WIRE BLK/GRN WIRE BLK/WHT WIRE BLU WIRE BLU/ORG WIRE BRN WIRE BRN/YEL WIRE COMBINATION METER FUSE 18 FUSE 8 FUSE/ RELAY BOX (BEHIND LEFT SIDE OF DASH) GB-7 (LEFT SIDE OF CENTER CONSOLE) GRN WIRE GRN/BLK WIRE GRN/WHT WIRE HOT AT ALL TIMES HOT AT ALL TIMES SBF HOLDER (AT LEFT SIDE OF ENGINE COMPT) SBF-7 FUSE HOT IN ON OR START LEFT FRONT ABS SENSOR LEFT REAR ABS SENSOR LT BLU WIRE LT GRN WIRE LT GRN/BLK WIRE LT GRN/YEL WIRE NCA WIRE PNK WIRE RED WIRE RED/BLK WIRE RED/WHT WIRE RED/YEL WIRE RIGHT FRONT ABS SENSOR RIGHT REAR ABS SENSOR SHIELD J/C (LEFT REAR OF ENGINE COMPT) STEERING ANGLE SENSOR (BEHIND LEFT SIDE OF DASH) STEERING ANGLE SENSOR J/C (BEHIND LEFT SIDE OF DASH) TRANSMISSION CONTROL MODULE (BEHIND LEFT SIDE OF DASH) VDC OFF INDICATOR LIGHT VDC OFF SWITCH VDC OPERATION INDICATOR LIGHT VDC WARNING LIGHT VIO WIRE WHT WIRE WHT/RED WIRE YAW RATE SENSOR (BELOW CENTER CONSOLE) YEL WIRE YEL/GRN WIRE
