Subaru Legacy BE/BH/BT (1998-2004) sub woofer left front door tweeter Wiring diagram
This page shows the only wiring diagram for the component.sub woofer left front door tweeter, which is found in the car Subaru Legacy BE/BH/BT (1998-2004). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram sub woofer left front door tweeter (1 of 1)
ANTENNA AMPLIFIER (RIGHT SIDE OF LUGGAGE COMPT)
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BLU/RED WIRE
BLU/YEL WIRE
BRN WIRE
BRN/WHT WIRE
DIN CORD
FUSE 2
FUSE 9
FUSE/ RELAY BOX
GB-9 (UNDER RIGHT FRONT SEAT)
GR (RIGHT SIDE OF CENTER CONSOLE)
GRN WIRE
HOT AT ALL TIMES
HOT IN ACC, ON
LEFT FRONT DOOR SPEAKER
LEFT REAR DOOR SPEAKER
LT GRN WIRE
MAIN FUSE BOX
NCA WIRE
ORG/ WIRE
PNK WIRE
POWER AMPLIFIER (CENTER OF DASH)
RADIO
RED WIRE
RED/BLK WIRE
RED/WHT WIRE
RED/YEL WIRE
RELAY BLOCK (BEHIND LEFT SIDE OF DASH)
RIGHT FRONT DOOR SPEAKER
RIGHT FRONT DOOR TWEETER
RIGHT REAR DOOR SPEAKER
SBF HOLDER (LEFT SIDE OF ENGINE COMPT)
SBF-8 FUSE
SUB WOOFER LEFT FRONT DOOR TWEETER
VIO WIRE
WHT WIRE
WHT/BLK WIRE
WHT/RED WIRE
YEL WIRE
YEL/GRN WIRE
Go to component -> Radio circuits, with macintosh audio system -> SUB WOOFER LEFT FRONT DOOR TWEETER
