Subaru Legacy BE/BH/BT (1998-2004) power window main switch illumination light Wiring diagrams
This page contains all the electrical diagrams for the component. power window main switch illumination light, in which he is found in the car Subaru Legacy BE/BH/BT (1998-2004). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram power window main switch illumination light (1 of 2)
A/T SELECTOR LEVER ILLUMINATION LIGHT
ASHTRAY ILLUMINATION LIGHT
AUTO A/C CONTROL MODULE ILLUMINATION
BLK WIRE
BLK/WHT WIRE
BLU WIRE
CD PLAYER ILLUMINATION LIGHT
COMBINATION METER
COMBINATION SWITCH
CRUISE CONTROL MAIN SWITCH ILLUMINATION LIGHT
FRONT ACCESSORY POWER SUPPLY SOCKET ILLUMINATION LIGHT
FRONT FOG LIGHT SWITCH ILLUMINATION LIGHT
FUSE 12
FUSE 7
FUSE/ RELAY BOX
GB-5 (BEHIND CENTER OF DASH)
GLOVE BOX ILLUMI- NATION LIGHT
GRY WIRE
HAZARD SWITCH ILLUMINATION LIGHT
HEAD OFF PARK
HOT AT ALL TIMES
HOT IN ON, START
ILLUMINATION CONTROL MODULE (ON TOP OF STEERING COLUMN)
ILLUMINATION LIGHT
LEFT SEAT HEATER SWITCH ILLUMINATION LIGHT
LIGHT SWITCH
LT GRN WIRE
MAIN FUSE BOX
MODE CONTROL PANEL ILLUMINATION LIGHT
POWER WINDOW MAIN SWITCH ILLUMINATION LIGHT
RADIO ILLUMINATION LIGHT
RIGHT SEAT HEATER SWITCH ILLUMINATION LIGHT
TAIL, ILLUMINATION RELAY
VIO WIRE
WHT WIRE
WIPER DEICER SWITCH ILLUMINATION LIGHT
Go to component -> Instrument illumination circuit -> POWER WINDOW MAIN SWITCH ILLUMINATION LIGHT
Wiring diagram power window main switch illumination light (2 of 2)
2.5L
2.5L 3.0L 7 5
3.0L
A/T SELECTOR LEVER ILLUMINATION LIGHT ILLUMINATION CONTROL MODULE
ABS CONTROL MODULE
AIR CONDITIONING RELAY
AIR CONDITIONING RELAY HOLDER
AIRBAG CONTROL MODULE
AUTO A/C CONTROL MODULE
BACK-UP LIGHT SWITCH (M/T) INHIBITOR SWITCH (A/T) A/T SHIFT LOCK CONTROL MODULE
BLK WIRE
BLK/WHT WIRE
BLU WIRE
CD ILLUMINATION LIGHT
CRUISE CONTROL MAIN SWITCH
CRUISE CONTROL MODULE WIPER DEICER RELAY WIPER DEICER TIMER
DAYTIME RUNNING LIGHTS CONTROL MODULE
ENGINE CONTROL MODULE
FAN RELAY A/C PRESSURE SWITCH
FROM FUSE/ RELAY BOX
FROM IGNITION SWITCH (DIAGRAM 2 OF 4)
FRONT FOG LIGHT SWITCH ILLUMINATION LIGHT
FUSE 11
FUSE 12
FUSE 17
FUSE 18
FUSE 6
FUSE/ RELAY BOX
GLOVE BOX ILLUMINATION LIGHT
GRN WIRE
GRN/BLK WIRE
GRN/RED WIRE
HAZARD SWITCH ILLUMINATION LIGHT
IGNITION COIL 5
IGNITION COIL 6
IGNITION COIL IGNITION COIL 1 IGNITION COIL 2 IGNITION COIL 3 IGNITION COIL 4
LEFT SEAT HEATER SWITCH ILLUMINATION LIGHT
LT GRN WIRE
MAIN FAN RELAY
MODE CONTROL PANEL
MODE CONTROL PANEL ILLUMINATION LIGHT
PARKING SWITCH
POWER WINDOW
POWER WINDOW MAIN SWITCH ILLUMINATION LIGHT
REAR DEFOGGER RELAY
RED WIRE
RIGHT SEAT HEATER SWITCH ILLUMINATION LIGHT
SUB FAN RELAY 1 (3.0L)
SUB FAN RELAY SUB FAN RELAY 2
TAIL, ILLUMINATION RELAY
VDC OFF SWITCH
VEHICLE DYNAMIC CONTROL MODULE
VIO WIRE
WHT WIRE
WIPER DEICER SWITCH ILLUMINATION LIGHT
YEL WIRE
Go to component -> Power distribution circuit (3 of 4) -> POWER WINDOW MAIN SWITCH ILLUMINATION LIGHT
