Subaru Legacy BE/BH/BT (1998-2004) mode control panel Wiring diagrams

A/T AIR CONDITIONING RELAY AIR CONDITIONING RELAY HOLDER (AT LEFT SIDE OF ENGINE COMPARTMENT) BLK WIRE BLK/BLU WIRE BLK/GRN WIRE BLK/RED WIRE BLK/WHT WIRE BLK/YEL WIRE BLOWER MOTOR (BEHIND RIGHT SIDE OF DASH) BLOWER MOTOR RELAY (BEHIND LEFT KICK PANEL) BLOWER MOTOR RESISTOR (BEHIND RIGHT SIDE OF DASH) BLU WIRE BLU/ORG WIRE BLU/WHT WIRE BLU/YEL WIRE ENGINE CONTROL MODULE (ECM) (BEHIND RIGHT SIDE OF DASH) EVAPORATION THERMOSWITCH (BEHIND RIGHT SIDE OF DASH, ON INTAKE UNIT CASE) FRESH/RECIRC ACTUATOR (ON RIGHT SIDE OF UPPER INTAKE UNIT CASE) FUSE FUSE 17 FUSE 18 FUSE 2 FUSE 1 FUSE, RELAY BOX (F/B) (BEHIND LEFT SIDE OF DASH) GB-2 (BEHIND LEFT HEADLIGHT) GB-5 (BELOW CENTER OF DASH) GB-7 (BELOW CENTER OF DASH) GRN VIO/ WIRE GRN/BLK WIRE GRN/BLU WIRE GRN/RED WIRE HOT AT ALL TIMES HOT IN ON OR START LT GRN/RED WIRE LT GRN/WHT WIRE M/T MAGNET CLUTCH MAIN FAN MOTOR MAIN FAN RELAY MODE ACTUATOR (BEHIND CENTER OF DASH) MODE CONTROL PANEL NCA WIRE PNK/GRN WIRE PRESSURE SWITCH (ON A/C RECEIVER-DRIER) REAR DEFOGGER RELAY RED WIRE RED/ WHT WIRE RED/BLK WIRE RED/BLU WIRE RED/WHT WIRE RED/YEL WIRE SUB FAN MOTOR SUB FAN RELAY VIO WIRE VIO/GRN WIRE VIO/RED WIRE VIO/YEL WIRE WHT WIRE WHT/BLK WIRE WHT/ORG WIRE YEL WIRE YEL/GRN WIRE YEL/RED WIRE

2.5L 2.5L 3.0L 7 5 3.0L A/T SELECTOR LEVER ILLUMINATION LIGHT ILLUMINATION CONTROL MODULE ABS CONTROL MODULE AIR CONDITIONING RELAY AIR CONDITIONING RELAY HOLDER AIRBAG CONTROL MODULE AUTO A/C CONTROL MODULE BACK-UP LIGHT SWITCH (M/T) INHIBITOR SWITCH (A/T) A/T SHIFT LOCK CONTROL MODULE BLK WIRE BLK/WHT WIRE BLU WIRE CD ILLUMINATION LIGHT CRUISE CONTROL MAIN SWITCH CRUISE CONTROL MODULE WIPER DEICER RELAY WIPER DEICER TIMER DAYTIME RUNNING LIGHTS CONTROL MODULE ENGINE CONTROL MODULE FAN RELAY A/C PRESSURE SWITCH FROM FUSE/ RELAY BOX FROM IGNITION SWITCH (DIAGRAM 2 OF 4) FRONT FOG LIGHT SWITCH ILLUMINATION LIGHT FUSE 11 FUSE 12 FUSE 17 FUSE 18 FUSE 6 FUSE/ RELAY BOX GLOVE BOX ILLUMINATION LIGHT GRN WIRE GRN/BLK WIRE GRN/RED WIRE HAZARD SWITCH ILLUMINATION LIGHT IGNITION COIL 5 IGNITION COIL 6 IGNITION COIL IGNITION COIL 1 IGNITION COIL 2 IGNITION COIL 3 IGNITION COIL 4 LEFT SEAT HEATER SWITCH ILLUMINATION LIGHT LT GRN WIRE MAIN FAN RELAY MODE CONTROL PANEL MODE CONTROL PANEL ILLUMINATION LIGHT PARKING SWITCH POWER WINDOW POWER WINDOW MAIN SWITCH ILLUMINATION LIGHT REAR DEFOGGER RELAY RED WIRE RIGHT SEAT HEATER SWITCH ILLUMINATION LIGHT SUB FAN RELAY 1 (3.0L) SUB FAN RELAY SUB FAN RELAY 2 TAIL, ILLUMINATION RELAY VDC OFF SWITCH VEHICLE DYNAMIC CONTROL MODULE VIO WIRE WHT WIRE WIPER DEICER SWITCH ILLUMINATION LIGHT YEL WIRE
