Subaru Legacy BE/BH/BT (1998-2004) left speaker joint connector Wiring diagram
This page shows the only wiring diagram for the component.left speaker joint connector, which is found in the car Subaru Legacy BE/BH/BT (1998-2004). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left speaker joint connector (1 of 1)
ANTENNA AMPLIFIER LEFT SIDE OF LUGGAGE COMPT)
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BLU/RED WIRE
BLU/YEL WIRE
BRN WIRE
BRN/WHT WIRE
FUSE 2
FUSE 9
FUSE/ RELAY BOX
GR (RIGHT SIDE OF CENTER CONSOLE)
GRN WIRE
HOT AT ALL TIMES
HOT IN ACC, ON
LEFT FRONT DOOR SPEAKER
LEFT FRONT DOOR TWEETER
LEFT REAR DOOR SPEAKER
LEFT REAR TWEETER
LEFT SPEAKER JOINT CONNECTOR
MAIN FUSE BOX
RADIO
RED WIRE
RED/BLK WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT FRONT DOOR SPEAKER
RIGHT FRONT DOOR TWEETER
RIGHT REAR DOOR SPEAKER
RIGHT REAR TWEETER
RIGHT SPEAKER JOINT CONNECTOR
VIO WIRE
W/ REAR TWEETER SPEAKER
W/O REAR TWEETER SPEAKER
WHT WIRE
WHT/BLK WIRE
WHT/RED WIRE
YEL WIRE
YEL/GRN WIRE
Go to component -> Radio circuits, without macintosh audio system -> LEFT SPEAKER JOINT CONNECTOR
