Subaru Legacy BE/BH/BT (1998-2004) hot in accy, on fuse, relay box fuse 15 Wiring diagram
This page shows the only wiring diagram for the component.hot in accy, on fuse, relay box fuse 15, which is found in the car Subaru Legacy BE/BH/BT (1998-2004). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram hot in accy, on fuse, relay box fuse 15 (1 of 1)
BLK WIRE
BLK/BLU WIRE
COMBINATION SWITCH
FRONT WASHER MOTOR (AT BOTTOM OF WASHER TANK)
FRONT WIPER MOTOR LO HIGH
GB-3 (LEFT SIDE OF FIREWALL)
GRN/YEL WIRE
HI OFF
HOT IN ACCY, ON FUSE, RELAY BOX FUSE 15
INTERMITTENT WIPER TIME CONTROL
INTERMITTENT WIPER UNIT
LT GRN/RED WIRE
MIST OFF HI OFF MIST SWITCH INT LO
NCA WIRE
OFF
OFF HI INT LO LO
PARK
REAR WIPER CIRCUIT
RED/BLU WIRE
RUN WIRE
WASHER SWITCH
WIPER MOTOR
WIPER SWITCH
YEL WIRE
YEL/BLK WIRE
Go to component -> Front washer/wiper circuit -> HOT IN ACCY, ON FUSE, RELAY BOX FUSE 15
