Subaru Legacy BE/BH/BT (1998-2004) hot in acc, on main fuse box fuse 4 Wiring diagram
This page shows the only wiring diagram for the component.hot in acc, on main fuse box fuse 4, which is found in the car Subaru Legacy BE/BH/BT (1998-2004). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram hot in acc, on main fuse box fuse 4 (1 of 1)
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BLU/WHT WIRE
FUSE/ RELAY BOX
GB-3 (LEFT SIDE OF FIREWALL)
GB-9 (RIGHT SIDE OF CENTER CONSOLE)
HIGH OFF LOW
HOT AT ALL TIMES
HOT IN ACC, ON MAIN FUSE BOX FUSE 4
LEFT SEAT HEATER
LEFT SEAT HEATER SWITCH
LT GRN WIRE
NCA WIRE
RED WIRE
RED/BLU WIRE
RED/WHT WIRE
RIGHT SEAT HEATER
RIGHT SEAT HEATER SWITCH
SBF-2 FUSE
SEAT HEATER FUSE HOLDER (ON RELAY BLOCK)
SEAT HEATER/ REAR ACCESSORY POWER SUPPLY RELAY (BEHIND LEFT SIDE OF DASH)
VIO WIRE
YEL WIRE
YEL/RED WIRE
Go to component -> Heated seats circuit -> HOT IN ACC, ON MAIN FUSE BOX FUSE 4
