Subaru Legacy BE/BH/BT (1998-2004) hi pass pass lo lo dimmer/ passing switch Wiring diagram
This page shows the only wiring diagram for the component.hi pass pass lo lo dimmer/ passing switch, which is found in the car Subaru Legacy BE/BH/BT (1998-2004). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram hi pass pass lo lo dimmer/ passing switch (1 of 1)
2 LIGHT MODEL
26 30 2.5L 3.0L
28 31 2.5L 3.0L
29 25 3.0L 2.5L
33 27 3.0L 2.5L
4 LIGHT MODEL
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BLU/WHT WIRE
BLU/YEL WIRE
COMBINATION METER
COMBINATION SWITCH
DAYTIME RUNNING LIGHT MODULE (BEHIND CENTER OF DASH)
DAYTIME RUNNING LIGHT RELAY (4 LIGHT MODEL) (IN RELAY BLOCK)
FOGLIGHT SWITCH
FRONT FOG- LIGHT DIODE (BEHIND LEFT SIDE OF DASH)
FRONT FOGLIGHT RELAY (IN A/C RELAY HOLDER)
FUSE 11
FUSE 7
FUSE 8
FUSE 9
FUSE/ RELAY BOX (BEHIND LEFT SIDE OF DASH)
GB-2 (BEHIND LEFT HEADLIGHT)
GB-7 (LEFT SIDE OF CENTER CONSOLE)
GRN WIRE
GRN/RED WIRE
HI PASS PASS LO LO DIMMER/ PASSING SWITCH
HI-BEAM IND
HOT AT ALL TIMES
HOT IN ON, START
IGNITION SWITCH
INSTRUMENT CLUSTER SYSTEM (PARK BRAKE WARNING INDICATOR) PNK WIRE
LEFT FOG LIGHT
LEFT HEADLIGHT
LEFT HEADLIGHT RELAY
LIGHT SWITCH
MAIN FUSE BOX (AT LEFT SIDE OF ENGINE COMPT, AT REAR OF BATTERY)
OFF
ON OFF
OPTION CONNECTOR (BEHIND CENTER OF DASH)
ORG/ WIRE
PARK HEAD OFF
PARKING BRAKE SWITCH (BASE OF PARK BRAKE LEVER)
PNK (OR WIRE
PNK WIRE
RED WIRE
RED/BLU WIRE
RED/GRN (OR RED/BLU) WIRE
RED/GRN WIRE
RED/YEL WIRE
RIGHT FOG LIGHT
RIGHT HEADLIGHT
RIGHT HEADLIGHT RELAY
STARTING/ CHARGING SYSTEM
VIO WIRE
WHT WIRE
WHT/BLK WIRE
WHT/GRN WIRE
YEL WIRE
YEL/BLU WIRE
Go to component -> Headlight circuit -> HI PASS PASS LO LO DIMMER/ PASSING SWITCH
