Subaru Legacy BE/BH/BT (1998-2004) custom cpu Wiring diagram

13 14 15 PNK WIRE AIR ASSIST INJECTOR SOLENOID VALVE (ON INTAKE MANIFOLD) AIR CONDITIONING SYSTEM BLK WIRE BLK/BLU WIRE BLK/LT GRN WIRE BLK/PNK WIRE BLK/RED WIRE BLK/WHT WIRE BLK/YEL WIRE BLU WIRE BLU/ORG WIRE BRN WIRE BRN/GRN WIRE BRN/RED WIRE BRN/YEL WIRE COMBINATION METER COOLING FANS SYSTEM CUSTOM CPU ENGINE CONTROL MODULE (BEHIND RIGHT SIDE OF DASH) FUEL INJECTORS FUSE 5 FUSE SBF-5 FUSE/ RELAY BOX (BEHIND LEFT SIDE OF DASH) GB-3 (CENTER OF FIRE- WALL) GE (REAR OF ENG) GRN WIRE GRN/BLK WIRE GRN/BLU WIRE GRN/RED WIRE GRN/WHT WIRE HOT AT ALL TIMES IDLE AIR CONTROL SOLENOID VALVE (ON THROTTLE BODY) IGNITION COIL, IGNITOR (TOP FRONT OF ENG) LT BLU WIRE LT BLU/BLK/LT GRN WIRE LT GRN WIRE LT GRN/BLK WIRE LT GRN/RED WIRE MAIN FUSE BOX (LEFT SIDE OF ENG COMPT, REAR OF BATTERY) MAL- FUNCTION INDICATOR LAMP OP CONNECTOR (BEHIND CENTER OF DASH) ORG/ WIRE ORG/WHT WIRE PNK PNK WIRE PNK WIRE PNK/BLK WIRE PNK/BLU WIRE PNK/GRN WIRE RED/BLK WIRE RED/BLU WIRE RED/GRN WIRE RED/WHT WIRE RED/YEL WIRE SPEEDO- METER CIRCUIT TACHO- METER TEST MODE CONNECTOR (BEHIND CENTER OF DASH) TRANSMISSION CONTROL MODULE (BEHIND CENTER OF DASH) WHT/BLK WIRE WHT/BLU WIRE WHT/LT BLU WIRE WHT/RED WIRE YEL WIRE YEL/GRN WIRE YEL/LT GRN WIRE YEL/RED WIRE
