Anti-lock brake circuits for Subaru Legacy BD/BG/BK (1993-1999)

ABS G SENSOR (CENTER OF PASS COMPT, ON FLOOR) ABS INDICATOR BLK WIRE BLU WIRE BLU/WHT WIRE CHECK CONNECTOR (LEFT SIDE OF DASH) COMBINATION METER DATA LINK CONNECTOR (RIGHT OF STEERING COLUMN) DIAGNOSIS CONNECTOR (LEFT SIDE OF DASH) FUSE 12 FUSE 15 FUSE 18 FUSE 19 FUSE/ RELAY BOX GRN/WHT WIRE HOT AT ALL TIMES HOT AT ALL TIMES SBF HOLDER SBF-6 FUSE HOT IN RUN OR START LEFT FRONT ABS SENSOR LEFT REAR ABS SENSOR LT GRN/RED WIRE LT GRN/WHT WIRE LT GRN/YEL WIRE NCA WIRE ORG/WHT WIRE PNK WIRE RED WIRE RED/BLK WIRE RIGHT FRONT ABS SENSOR STOPLIGHT SWITCH (ON BRACKET, ABOVE BRAKE PEDAL) TRANSMISSION CONTROL MODULE (BEHIND LEFT SIDE OF DASH) TWISTED PAIR W/ CRUISE W/O CRUISE WHT WIRE WHT/BLK WIRE WHT/GRN WIRE WHT/RED WIRE
