Subaru Legacy BD/BG/BK (1993-1999) stop and brake switch or pedal stroke switch Wiring diagram
This page shows the only wiring diagram for the component.stop and brake switch or pedal stroke switch, which is found in the car Subaru Legacy BD/BG/BK (1993-1999). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram stop and brake switch or pedal stroke switch (1 of 1)
1 2 3 OTHERS W/ CRUISE CONTROL W/ TRACTION CONTROL
A/T SHIFT LOCK CONTROL MODULE HEAD- LIGHT ALARM RELAY
BATTERY
BLK WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
BLU/BLK WIRE
BRN WIRE
COMBINATION METER
DOOR LOCK TIMER
ENGINE CONTROL MODULE
FROM IGNITION SWITCH (DIAGRAM 2 OF 3)
FRONT FOG LIGHT RELAY
FUEL PUMP RELAY
FUSE 11
FUSE 12 FUSE 19
FUSE 20 FUSE 21
FUSE 22
FUSE 23
FUSE 24
FUSE 25
FUSE 26
FUSE 6
FUSE/ RELAY BOX
FUSIBLE LINK
GRN/WHT WIRE
HAZARD SWITCH
HEADLIGHT ALARM RELAY
HEADLIGHT ALARM RELAY SECURITY INDICATOR LIGHT
HEADLIGHTS SYSTEM
HORN RELAY BLOWER MOTOR RELAY HYDRAULIC UNIT
INTERRUPT RELAY
LEFT HEADLIGHT RELAY
LEFT RIGHT
LUGGAGE ROOM LIGHT (WAGON) TRUNK ROOM LIGHT (SEDAN)
MAIN FUSE BOX
MAIN RELAY
NCA WIRE
OBD-II SERVICE CONNECTOR
PARKING SWITCH
POWER ANTENNA KEY WARNING SWITCH
POWER WINDOW, SUNROOF CIRCUIT BREAKER
POWER WINDOW, SUNROOF RELAY
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/YEL WIRE
RIGHT HEADLIGHT RELAY
SBF-1 FUSE
SBF-2 FUSE
SBF-3 FUSE
SECURITY CONTROL MODULE
SPOT LIGHT
STARTER MOTOR
STEP LIGHTS ROOM LIGHT RADIO
STOP AND BRAKE SWITCH OR PEDAL STROKE SWITCH
TO FUSE/RELAY BOX TAIL/ ILLUMINATION RELAY (DIAGRAM 3 OF 3)
TO MAIN FUSE BOX (DIAGRAM 2 OF 3)
TRAILER CONNECTOR (OUTBACK)
W/ ANTI- THEFT
W/O ANTI- THEFT
WHT WIRE
WHT/BLU WIRE
WHT/GRN WIRE
YEL WIRE
YEL/GRN WIRE
Go to component -> Power distribution circuit (1 of 3) -> STOP AND BRAKE SWITCH OR PEDAL STROKE SWITCH
