Subaru Legacy BD/BG/BK (1993-1999) shift solenoid 3 Wiring diagram

3 2 DATA LINK CONNECTOR (BEHIND DASH, RIGHT OF STEERING COLUMN) 7 10 9 8 CHECK CONNECTOR (BEHIND DASH, RIGHT OF STEERING COLUMN) A/T CONTROL (TRANSMISSION) A/T OIL TEMP IND ANTI-LOCK BRAKES SYSTEM ATF TEMPERATURE SENSOR AWD SOLENOID BLK RED/ WIRE BLK WIRE BLK/BLU WIRE BLK/PNK WIRE BLK/RED WIRE BLK/YEL WIRE BLU WIRE BLU/GRN WIRE BLU/RED WIRE BLU/WHT WIRE BLU/YEL WIRE BRN/YEL WIRE COMBINATION METER CRUISE CONTROL SYSTEM DIAGNOSIS CONNECTOR (BEHIND DASH, RIGHT OF STEERING COLUMN) ENGINE CONTROL MODULE (ECM) (UNDER RIGHT SIDE OF DASH) FUSE 14 FUSE 15 FUSE 16 FUSE 12 FUSE/ RELAY BOX (BEHIND DASH, LEFT OF STEERING COLUMN) FWD IND FWD SWITCH (W/ AWD) (RIGHT REAR OF ENGINE COMPARTMENT) GRN WIRE GRN/BLK WIRE GRN/ORG WIRE GRN/WHT WIRE GRN/YEL WIRE HOT AT ALL TIMES HOT AT ALL TIMES HOT IN ON OR START HOT IN ON OR START INHIBITOR SWITCH (ON RIGHT SIDE OF TRANSMISSION) LOCK-UP SOLENOID LT BLU WIRE LT GRN/BLK WIRE LT GRN/RED WIRE NCA WIRE PNK WIRE RED WIRE RED/BLK WIRE RED/BLU WIRE RED/WHT WIRE RED/YEL WIRE SHIELD JOINT CONNECTOR (BEHIND DASH, TAPED TO TCM BREAKOUT) SHIFT SOLENOID 1 SHIFT SOLENOID 3 SOLENOID 2 SHIFT SOLENOID LINE PRESSURE SPEEDOMETER STOP LAMP SWITCH (ON BRACKET ABOVE PEDAL BRACKET) THROTTLE POSITION SENSOR (ON THROTTLE BODY) TRANSMISSION CONTROL MODULE (TCM) (BEHIND LEFT SIDE OF DASH) VEHICLE SPEED SENSOR 2 (ON TRANSMISSION) WHT WIRE WHT/BLK WIRE WHT/BLU WIRE YEL WIRE YEL/BLU WIRE YEL/GRN WIRE YEL/RED WIRE
