Subaru Legacy BD/BG/BK (1993-1999) right front turn signal/ side marker light Wiring diagram
This page shows the only wiring diagram for the component.right front turn signal/ side marker light, which is found in the car Subaru Legacy BD/BG/BK (1993-1999). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right front turn signal/ side marker light (1 of 1)
ABS CONTROL MODULE
ABS RELAY BOX
BLK WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BRAKE FLUID LEVEL SWITCH
CHECK CONNECTOR
COMBINATION METER
CRUISE CONTROL MODULE DRL RESISTOR
DATALINK CONNECTOR
DAYTIME RUNNING LIGHTS CONTROL MODULE
DOOR LOCK MODULE
ENGINE CONTROL MODULE
FROM SUB FAN MOTOR (DIAGRAM 2 OF 3)
FROM TCS CONTROL MODULE (DIAGRAM 2 OF 3)
FROM TRAILER CONNECTOR (DIAGRAM 3 OF 3)
FRONT WIPER MOTOR
FUEL PUMP AND FUEL GAUGE MODULE (2.2L AWD)
FWD SWITCH
IGNITOR
M/T
NEUTRAL POSITION SWITCH (M/T)
OBD-II SERVICE CONNECTOR
OUTBACK STEP ROOF MODEL ALL OTHERS
RADIO
REAR DEFOGGER (SEDAN)
REAR POWER SUPPLY RELAY
RIGHT FRONT DOOR LOCK ACTUATOR RIGHT FRONT DOOR KEY SWITCH (ANTI-THEFT)
RIGHT FRONT DOOR LOCK SWITCH
RIGHT FRONT FOG LIGHT
RIGHT FRONT TURN SIGNAL/ SIDE MARKER LIGHT
RIGHT VANITY MIRROR ILLUMINATION LIGHT
SECURITY CONTROL MODULE
SHIELD JOINT CONNECTOR (ABS)
SRS HARNESS
TCS MAIN RELAY
TEST MODE CONNECTOR
W/O TCS
Go to component -> Ground distribution circuit (1 of 3) -> RIGHT FRONT TURN SIGNAL/ SIDE MARKER LIGHT
