Subaru Legacy BD/BG/BK (1993-1999) remote control rearview mirror switch Wiring diagram
This page shows the only wiring diagram for the component.remote control rearview mirror switch, which is found in the car Subaru Legacy BD/BG/BK (1993-1999). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram remote control rearview mirror switch (1 of 1)
A/T SHIFT LOCK CONTROL MODULE
ABS SHIELD JOINT CONNECTOR (TCS)
ASH TRAY ILLUMINATION LIGHT
BLK WIRE
CLUTCH SWITCH (M/T)
COMBINATION METER
COMBINATION SWITCH
CRUISE CONTROL MAIN SWITCH
DIAGNOSIS TERMINAL
FAN SWITCH
FRONT ACCESSORY POWER OUTLET
FRONT HOOD SWITCH (ANTI- THEFT)
GLOVE BOX ILLUMINATION LIGHT
ILLUMINATION CONTROL MODULE
LEFT FRONT DOOR KEY SWITCH (ANTI-THEFT) LEFT FRONT DOOR LOCK ACTUATOR
LEFT FRONT DOOR LOCK SWITCH
LEFT FRONT FOG LIGHT
LEFT FRONT TURN SIGNAL, SIDE MARKER LIGHT
LEFT VANITY MIRROR ILLUMINATION LIGHT
MAIN FAN MOTOR
MAIN RELAY
MODE ACTUATOR
MODE CONTROL PANEL
OUTBACK STEP ROOF MODEL ALL OTHERS
POWER WINDOW AND SUNROOF RELAY
POWER WINDOW MAIN SWITCH
REAR DEFOGGER SWITCH
REMOTE CONTROL REARVIEW MIRROR SWITCH
SEAT BELT TIMER
SUB FAN MOTOR
TCS CONTROL MODULE
TCS MOTOR
TURN SIGNAL AND HAZARD MODULE
Go to component -> Ground distribution circuit (2 of 3) -> REMOTE CONTROL REARVIEW MIRROR SWITCH
