Subaru Legacy BD/BG/BK (1993-1999) radio illumination light Wiring diagram
This page shows the only wiring diagram for the component.radio illumination light, which is found in the car Subaru Legacy BD/BG/BK (1993-1999). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram radio illumination light (1 of 1)
A/T SELECTOR LEVER ILLUMINATION LIGHT
ASHTRAY ILLUMINATION LIGHT
BLK WIRE
BLK/GRN WIRE
BLK/RED WIRE
BLU WIRE
BLU/RED WIRE
BRN WIRE
BRN/RED WIRE
CD PLAYER ILLUMINATION LIGHT
COMBINATION METER
COMBINATION SWITCH
CRUISE CONTROL MAIN SWITCH ILLUMINATION LIGHT
FRONT FOG LIGHT SWITCH ILLUMINATION LIGHT
FUSE 23
FUSE 9
FUSE/ RELAY BOX
GLOVE BOX ILLUMI- NATION LIGHT
HAZARD SWITCH ILLUMINATION LIGHT
HEAD OFF PARK
HOT AT ALL TIMES
HOT IN ON, START
ILLUMINATION CONTROL MODULE (LEFT OF STEERING COLUMN)
ILLUMINATION LIGHT
LEFT SEAT HEATER SWITCH ILLUMINATION LIGHT (OUTBACK STEP ROOF MODEL)
LIGHT SWITCH
MAIN FUSE BOX
MODE CONTROL PANEL ILLUMINATION LIGHT
NCA WIRE
RADIO ILLUMINATION LIGHT
REAR DEFOGGER SWITCH ILLUMINATION LIGHT
RIGHT SEAT HEATER SWITCH ILLUMINATION LIGHT (OUTBACK STEP ROOF MODEL)
TAIL, ILLUMINATION RELAY
TCF OFF SWITCH ILLUMINATION LIGHT
WHT WIRE
WHT/GRN WIRE
WHT/YEL WIRE
YEL WIRE
YEL/BLU WIRE
