Subaru Legacy BD/BG/BK (1993-1999) off hi hi off int lo lo Wiring diagram
This page shows the only wiring diagram for the component.off hi hi off int lo lo, which is found in the car Subaru Legacy BD/BG/BK (1993-1999). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram off hi hi off int lo lo (1 of 1)
BLK WIRE
BLK/BLU WIRE
BLU WIRE
COMBINATION SWITCH
FRONT WASHER MOTOR (IN RESERVOIR)
FRONT WIPER MOTOR LO HIGH WIPER MOTOR PARK
FUSE 2
FUSE/ RELAY BOX
GRN/YEL WIRE
HOT IN ACC, ON
INTERMITTENT WIPER TIME CONTROL
INTERMITTENT WIPER UNIT
LT GRN/RED WIRE
MIST OFF MIST SWITCH
OFF
OFF HI HI OFF INT LO LO
OFF HI INT LO
RED/BLU WIRE
RUN WIRE
WASHER SWITCH
WHT WIRE
WHT/BLU WIRE
WIPER SWITCH
Go to component -> Front wiper/washer circuit -> OFF HI HI OFF INT LO LO
