Subaru Legacy BD/BG/BK (1993-1999) left step light Wiring diagram
This page shows the only wiring diagram for the component.left step light, which is found in the car Subaru Legacy BD/BG/BK (1993-1999). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left step light (1 of 1)
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BLU/BLK WIRE
BLU/ORG WIRE
BLU/RED WIRE
BLU/WHT WIRE
COMBINATION METER
DOOR
FUSE 25
FUSE 3
FUSE HOLDER
FUSE/ RELAY BOX
GRN/RED WIRE
HOT AT ALL TIMES
HOT IN ACC OR ON
LEFT FRONT DOOR LAMP
LEFT FRONT DOOR SWITCH
LEFT REAR DOOR LAMP
LEFT REAR DOOR SWITCH RIGHT REAR DOOR SWITCH
LEFT STEP LIGHT
LEFT VANITY MIRROR ILLUMI- NATION LIGHT
LT GRN WIRE
LT GRN/RED WIRE
LT GRN/YEL WIRE
LUGGAGE ROOM LIGHT (WAGON)
MAIN FUSE BOX
OFF
ON DOOR OFF
REAR ACCESSORY POWER SUPPLY SOCKET
REAR GATE DIODE (CENTER FRONT OF DASH AREA)
REAR GATE LAMP
REAR GATE LATCH SWITCH (WAGON)
REAR POWER SUPPLY RELAY (BEHIND RIGHT KICK PANEL)
RED WIRE
RED/WHT WIRE
RIGHT FRONT DOOR LAMP
RIGHT FRONT DOOR SWITCH
RIGHT REAR DOOR LAMP
RIGHT STEP LIGHT
RIGHT VANITY MIRROR ILLUMI- NATION LIGHT
ROOM LIGHT
SBF-5 FUSE
SPOT LIGHT
STEP LIGHT DIODE (LEFT SIDE OF DASH)
TRAILER CONNECTOR (OUTBACK STEP ROOF MODEL)
TRUNK ROOM LIGHT (SEDAN)
TRUNK ROOM LIGHT SWITCH (SEDAN)
YEL WIRE
YEL/BLK WIRE
YEL/RED WIRE
Go to component -> Courtesy lamps circuit -> LEFT STEP LIGHT
