Subaru Legacy BD/BG/BK (1993-1999) left rear speaker Wiring diagram
This page shows the only wiring diagram for the component.left rear speaker, which is found in the car Subaru Legacy BD/BG/BK (1993-1999). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left rear speaker (1 of 1)
BLK WIRE
BLU WIRE
BLU/RED WIRE
BLU/YEL WIRE
BRN/WHT WIRE
FUSE 17
FUSE 22
FUSE 25
FUSE/ RELAY BOX
GRN WIRE
GRN/ORG WIRE
HOT AT ALL TIMES
HOT IN ACC, ON
LEFT FRONT DOOR SPEAKER
LEFT FRONT TWEETER
LEFT REAR SPEAKER
MAIN FUSE BOX
POWER ANTENNA (LEFT REAR OF VEHICLE)
RADIO (LEFT SIDE OF DASH)
RED WIRE
RED/BLK WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT FRONT DOOR SPEAKER
RIGHT FRONT TWEETER
RIGHT REAR SPEAKER
SEDAN WAGON
WHT WIRE
WHT/BLK WIRE
WHT/GRN WIRE
WHT/RED WIRE
YEL WIRE
YEL/BLU WIRE
Go to component -> Radio circuits -> LEFT REAR SPEAKER
