Radio circuit, w/ audio amplifier & telematics for Subaru Impreza GK2 facelift (2019-2023)

ANTENNA ANTI-LOCK BRAKES SYSTEM AUDIO (W/O NAVIGATION) NAVIGATION UNIT (W/ NAVIGATION) AUDIO CASE GROUND AUX INPUT TERMINAL BEHIND REAR SEATS) BLK WIRE BLU WIRE BLU/RED WIRE BRN WIRE COMPUTER DATA LINES SYSTEM DATA COMMUNICATION MODULE (BEHIND CENTER OF DASH) ENGINE COMPARTMENT RELAY & FUSE BLOCK (M/B) FUSE 29 FUSE 4 GB-2 GB-3 GRN WIRE GRY WIRE HOT AT ALL TIMES HOT W/ ACCESSORY RELAY-1 ENERGIZED INSTRUMENT PANEL LT BLU WIRE LT GRN WIRE NAVIGATION SYSTEM NCA WIRE ORG/ WIRE OVERHEAD CONSOLE (MICROPHONE) PASSENGER COMPARTMENT FUSE, RELAY BLOCK (F/B) PNK WIRE PNK/BLK WIRE REAR VIEW CAMERA CIRCUIT RED WIRE SATELLITE ANTENNA SHIELD STEREO CAMERA COVER (MICROPHONE) TELEMATICS ANTENNA VIO WIRE W/ EYESIGHT W/O EYESIGHT WHT WIRE YEL WIRE

AIR BAG CONTROL MODULE BLK WIRE BLK/GRN WIRE BLK/PNK WIRE BLU WIRE BRN WIRE COMPUTER DATA LINES SYSTEM GB-3 GB-4 GPS ANTENNA GREEN GRN WIRE GRY WIRE ILLUMINATION INDICATOR LT GRN WIRE NCA WIRE ORG/ WIRE PNK WIRE RED WIRE SHIELD SOS TEL SUB ANTENNA TELEMATICS BUTTON VIO WIRE WHT WIRE YEL WIRE

BEHIND STEERING WHEEL) BLK WIRE BLU WIRE BRN WIRE CAN TRANSCEIVER COMBINATION METER COMPUTER DATA LINES SYSTEM DC/DC - FUSE 15 FUSE 8 GB-4 GRN WIRE GRY WIRE HOOK HOT W/ IG 1 RELAY ENERGIZED HOT W/ IG 2 RELAY ENERGIZED IGN ILL LEFT LEFT FRONT DOOR SPEAKER LEFT REAR DOOR SPEAKER LEFT SIDE TWEETER LT GRN WIRE MICROCOMPUTER NCA WIRE OFF ORG/ WIRE PASSENGER COMPARTMENT FUSE, RELAY BLOCK (F/B) PNK WIRE POWER DISTRIBUTION SYSTEM RED WIRE RIGHT RIGHT SIDE TWEETER ROLL CONNECTOR SATELLITE SWITCH SEEK SOURCE VIO WIRE VOICE VOL (-) WHT WIRE YEL WIRE

AUDIO AMPLIFIER BLK WIRE BLU WIRE BRN WIRE COMPUTER DATA LINES SYSTEM ENGINE COMPARTMENT RELAY & FUSE BLOCK (M/B) FUSE 18 FUSE 31 GB-6 GRN WIRE GRY WIRE HOT AT ALL TIMES LT BLU WIRE LT GRN WIRE MFD ORG/ WIRE PNK WIRE RED WIRE RED/WHT WIRE RIGHT FRONT DOOR SPEAKER RIGHT REAR DOOR SPEAKER SHIELD TAN WIRE VIO WIRE W/ HIGH GRADE MFD WHT WIRE YEL WIRE
