Subaru Impreza GK2 (2016-2019) trunk lid lock actuator, switch Wiring diagrams
This page contains all the electrical diagrams for the component. trunk lid lock actuator, switch, in which he is found in the car Subaru Impreza GK2 (2016-2019). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram trunk lid lock actuator, switch (1 of 3)
BLK WIRE
BLU WIRE
BODY INTEGRATED UNIT
BRN WIRE
COMPUTER DATA LINES SYSTEM
FUSE 36
FUSE 9
GB-5
GB-6
HATCHBACK
HOT AT ALL TIMES
HOT W/ ACCESSORY RELAY-1 ENERGIZED
KEY WARNING SWITCH (W/O PUSH BUTTON START) (AT IGNITION SWITCH)
LT GRN WIRE
LUGGAGE ROOM LIGHT
OFF
ORG/ WIRE
PASSENGER COMPARTMENT FUSE, RELAY BLOCK (F/B)
PNK WIRE
REAR GATE LOCK ACTUATOR, LATCH SWITCH
RED WIRE
RIGHT FRONT DOOR SWITCH
RIGHT REAR DOOR SWITCH
SEDAN
TRUNK LID LOCK ACTUATOR, SWITCH
TRUNK ROOM LIGHT
VIO WIRE
W/O PUSH BUTTON START W/ PUSH BUTTON START
YEL WIRE
Go to component -> Courtesy lamps circuit (2 of 2) -> TRUNK LID LOCK ACTUATOR, SWITCH
Wiring diagram trunk lid lock actuator, switch (2 of 3)
AUDIO AMPLIFIER
BLK WIRE
BLK/WHT WIRE
FB HEATER
FUEL PUMP ASSEMBLY
GB-5
GB-6
GT-1
HATCHBACK
HIGH MOUNTED STOP LIGHT
LEFT LICENSE PLATE LIGHT
LEFT REAR FINISHER LIGHT
REAR DEFOGGER
REAR GATE LOCK ACTUATOR, LATCH SWITCH
REAR GATE OPENER BUTTON
REAR GATE OPENER, REAR LOCK BUTTON
REAR WIPER MOTOR
RIGHT FRONT DOOR SWITCH
RIGHT LICENSE PLATE LIGHT
RIGHT RADAR SENSOR (SLAVE)
RIGHT REAR COMBINATION LIGHT
RIGHT REAR DOOR SWITCH
RIGHT REAR FINISHER LIGHT
RIGHT SEAT HEATER
SECONDARY SPEED SENSOR
SEDAN
TCM
TRUNK LID LOCK ACTUATOR, SWITCH
TRUNK OPENER BUTTON
TURBINE SPEED SENSOR
W/ BSD/ RCTA
Go to component -> Ground distribution circuit (4 of 5) -> TRUNK LID LOCK ACTUATOR, SWITCH
Wiring diagram trunk lid lock actuator, switch (3 of 3)
BLK WIRE
BLU WIRE
BODY INTEGRATED UNIT
BRN WIRE
COMPUTER DATA LINES SYSTEM
ENGINE COMPARTMENT RELAY & FUSE BLOCK (M/B)
FUSE 14
FUSE 17
FUSE 5
FUSE 9
GB-6
HATCHBACK
HOT AT ALL TIMES
HOT W/
HOT W/ ACCESSORY RELAY-1 ENERGIZED
KEYLESS ACCESS CONTROL MODULE
LT GRN WIRE
ORG/ WIRE
PASSENGER COMPARTMENT FUSE, RELAY BLOCK (F/B)
PNK WIRE
REAR GATE LOCK ACTUATOR, LATCH SWITCH
REAR GATE/ TRUNK UNLOCK RELAY
REAR LOCK BUTTON, REAR GATE OPENER BUTTON
RED WIRE
RIGHT END OF DASH)
SEDAN
TRUNK LID LOCK ACTUATOR, SWITCH
TRUNK OPENER BUTTON
VIO WIRE
WHT WIRE
YEL WIRE
Go to component -> Trunk/tailgate release circuit -> TRUNK LID LOCK ACTUATOR, SWITCH
