Subaru Impreza GK2 (2016-2019) right front fog light relay Wiring diagrams
This page contains all the electrical diagrams for the component. right front fog light relay, in which he is found in the car Subaru Impreza GK2 (2016-2019). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
right front fog light relay wiring diagram (1 of 2)
BLK WIRE
BLU WIRE
BRN WIRE
ENGINE COMPARTMENT RELAY & FUSE BLOCK (M/B)
FRONT FOG LIGHT RELAY
FUSE 36
GB-4
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
LEFT DAYTIME RUNNING LIGHT
LEFT FRONT FOG LIGHT
LEFT FRONT FOG LIGHT RELAY
LT BLU WIRE
OPTION CONNECTOR (FOG LIGHT SWITCH)
ORG/ WIRE
PNK WIRE
RED WIRE
RIGHT DAYTIME RUNNING LIGHT
RIGHT FRONT FOG LIGHT
RIGHT FRONT FOG LIGHT RELAY
RIGHT SIDE OF RADIATOR)
SRF OFF SWITCH
VIO WIRE
W/ AUTO LIGHT
W/ OPTION CONNECTOR W/O OPTION CONNECTOR HALOGEN W/ DAYTIME RUNNING LIGHT LED
W/ SRF
WHT WIRE
YEL WIRE
Go to component -> Headlamps circuit (2 of 3) -> RIGHT FRONT FOG LIGHT RELAY
right front fog light relay wiring diagram (2 of 2)
ACTIVE GRILLE SHUTTER
AUDIO (W/O NAVIGATION) NAVIGATION UNIT (W/ NAVIGATION)
AUDIO AMPLIFIER
BATTERY
BATTERY SENSOR
BLK WIRE
BLK/RED WIRE
BLOWER MOTOR RELAY
BLU WIRE
BLU/RED WIRE
DATA LINK CONNECTOR
ENGINE COMPARTMENT RELAY & FUSE BLOCK (M/B)
FRONT FOG LIGHT RELAY
FUSE 10
FUSE 11
FUSE 12
FUSE 15
FUSE 16
FUSE 29
FUSE 30
FUSE 31
FUSE 32
FUSE 33
FUSE 34
FUSE 35
FUSE 36
FUSE 37
FUSE 38
GENERATOR
GRN WIRE
GRN/BLU WIRE
GRY WIRE
H/L LO RELAY
HORN RELAY
LEFT FRONT FOG LIGHT RELAY
MAIN FAN RELAY 1
MAIN SBF FUSE
N/A
ORG/ WIRE
POWER AMPLIFIER
POWER STEERING CONTROL MODULE
REAR DEFOGGER RELAY
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT FRONT FOG LIGHT RELAY
SBF 10 FUSE
SBF 12 FUSE
SBF-11 FUSE
SBF-13 FUSE
SBF-14 FUSE
SBF-3 FUSE
SBF-4 FUSE
SBF-6 FUSE
SBF-9 FUSE
STARTER CUT RELAY
STARTER MOTOR
SUB FAN RELAY
TAN WIRE
TCM
TO MAIN RELAY (DIAGRAM 2 OF 7)
TO PASSENGER COMPARTMENT FUSE, RELAY BLOCK (F/B) (DIAGRAM 3 OF 7)
TO PASSENGER COMPARTMENT FUSE, RELAY BLOCK (F/B) (DIAGRAM 4 OF 7)
VDC CONTROL MODULE
W/ SRF
WHT WIRE
WHT/BLK WIRE
WHT/RED WIRE
WIPER DEICER RELAY
WIPER RELAY
YEL WIRE
Go to component -> Power distribution circuit (1 of 7) -> RIGHT FRONT FOG LIGHT RELAY
